Page 1/1
Blinking
WARRANTY
0.5W
Constant
off
Rapid Blink
Power / mode button
Mounting Hook
Micro USB Port CapLow Battery /
charge indicator
Rubber StrapsUSB-Micro USB Cable
Copyright © Topeak, Inc. 2015 M-TMS079-GB 11/15
MOUNTING ON HANDLEBAR
• Although light body is water-resistant (under normal weather conditions of
rain, etc.) never intentionally submerge it underwater.
• For ultimate safety, the WhiteLite™ Mini USB should be used in conjunction
with a specific night riding light.
• In addition to its brightness, the beam is widely diffused. In case you need to
use this light on public roads, be sure to adjust the angle downward so as
not to blind oncoming traffic.
WARNING
User's Guide
WHITELITE™ MINI USB
GB
BATTERY CHARGING
Standard charging time
3~4 hours (approx)
To computer USB
port or USB charger.
USB Micro USB
Open Micro USB Port Cap
X shaped Rubber Strap should
be centered on handlebar for
even tension.
Rubber Straps
Function : Blinking / 0.5W Constant /
Rapid Blink
Burn Time : 7 hr / 3 hr / 35 hr
Luminous : 60 Lumens
Lamp : 2 super bright 0.3W white LEDs
Battery : 3.7V 330mAh Lithium Ion
Charge : USB power supply 5V
500mA
Weight : 22 g / 0.78 oz (light only)
Reserve Time: 0.5 hr
SPECIFICATION
SPARE PARTS
• The WhiteLite™ Mini USB Charge Indicator will be lit GREEN when charging. LED will
turn off when battery is fully charged.
• The WhiteLite™ Mini USB Charge Indicator will be lit RED when the remaining battery
power is low. Please charge the light as soon as possible.
• The WhiteLite™ Mini USB LED will not illuminate if the battery is faulty.
• Disconnect the Micro-USB cable from your computer port when the WhiteLite Mini
USB is removed.
• After WhiteLite™ Mini USB is fully charged, unplug the USB cable.
• Do not open light body.
• Li-ion battery may take 3 to 5 charging cycles to attain full capacity.
• Do not leave battery connected to charge source over 48 hours continuously.
• Charging with USB hub will take longer.
• After long periods of non-use, the battery will lose charge. Always charge the battery
fully before each use and storage.
• Maintain the battery by charging it every two months and storing it in a cool, dry
place to prevent from decreasing its lifespan.
• Safely and properly dispose of the old Li-ion batteries according to your local
regulations.
1-year Warranty: All mechanical components against manufacturer defects only.
Warranty Claim Requirements
To obtain y se ou must h our o inal sales ned without a sales warrant rvice, y ave y rig receipt. Items retur receipt
will assume th t the y be ins on the d e of manufa ties will be oid if the p t is a warrant g at cture. All warran v roduc
damaged due o user c ash, abus em alt r e yst, s tera a ny wa nt rtion, modific tion, or used in a y not i ended as desc ibed
in this manual.
* The specifications and design are subject to change without notice.
Please contact your Topeak dealer with any questions.
For USA customer service, call: 1-800-250-3068
www.topeak.com
Art No. TMS-SP98Art No. TMS-SP99
(fits ø25.4 ~ ø31.8 mm)
(fits mm)ø31.8 ~ ø34.9
(fits mm)> ø34.9
(fits ø22.2 ~ ø25.4 mm)
(ø25.4 ~ ø31.8 mm)
( mm)ø22.2 ~ ø25.4
