Topeak MINI USB COMBO Manual
Read below 📖 the manual in Italian for Topeak MINI USB COMBO (2 pages) in the Lamp category. This guide has been helpful for 4 people and has been rated 4.5 stars on average by 2 users
Page 1/2
Blinking
0.5W
Constant
off
Rapid Blink
Power / mode button
Mounting Hook
Micro USB
Port Cap
Low Battery /
charge indicator
Rubber StrapsUSB-Micro USB Cable
MOUNTING ON HANDLEBAR
• Although light body is water-resistant (under normal weather conditions of
rain, etc.) never intentionally submerge it underwater.
• For ultimate safety, the WhiteLite™ Mini USB should be used in conjunction
with a specific night riding light.
• In addition to its brightness, the beam is widely diffused. In case you need to
use this light on public roads, be sure to adjust the angle downward so as
not to blind oncoming traffic.
WARNING
User's Guide
MINI USB COMBO GB
BATTERY CHARGING
Standard charging time
3~4 hours (approx)
To computer USB port or
USB charger.
USB Micro USB
Open Micro USB Port Cap
X shaped Rubber Strap should
be centered on handlebar for
even tension.
Function : Blinking / 0.5W Constant / Rapid Blink
Burn Time : 7 hr / 3 hr / 35 hr
Luminous : 60 Lumens
Lamp : 2 super bright 0.3W white LEDs
Battery : 3.7V 330mAh Lithium Ion
Charge : USB power supply 5V 500mA
Weight : 22 g / 0.78 oz (light only)
Reserve Time: 0.5 hr
SPECIFICATION
• The WhiteLite™ Mini USB Charge Indicator will be lit GREEN when charging. LED will
turn off when battery is fully charged.
• The WhiteLite™ Mini USB Charge Indicator will be lit RED when the remaining battery
power is low. Please charge the light as soon as possible.
• The WhiteLite™ Mini USB LED will not illuminate if the battery is faulty.
• Disconnect the Micro-USB cable from your computer port when the WhiteLite™ Mini
USB is removed.
• After WhiteLite™ Mini USB is fully charged, unplug the USB cable.
• Do not open light body.
• Li-ion battery may take 3 to 5 charging cycles to attain full capacity.
• Do not leave battery connected to charge source over 48 hours continuously.
• Charging with USB hub will take longer.
• After long periods of non-use, the battery will lose charge. Always charge the battery
fully before each use and storage.
• Maintain the battery by charging it every two months and storing it in a cool, dry
place to prevent from decreasing its lifespan.
• Safely and properly dispose of the old Li-ion batteries according to your local
regulations.
Rubber Straps
SPARE PARTS
WHITELITE™ MINI USB
Art No. TMS-SP98Art No. TMS-SP99
(fits ø25.4 ~ ø31.8 mm)
(fits mm)ø31.8 ~ ø34.9
(fits mm)> ø34.9
(fits ø12 ~ ø17 mm)
(ø25.4 ~ ø31.8 mm)
( mm)ø22.2 ~ ø25.4
User's Guide
MINI USB COMBO
WARRANTY
1-year Warranty: All mechanical components against manufacturer defects only.
Warranty Claim Requirements
To obtain y se ou must h our o inal sales ned without a sales warrant rvice, y ave y rig receipt. Items retur receipt
will assume th t the y be ins on the d e of manufa ties will be oid if the p t is a warrant g at cture. All warran v roduc
damaged due o user c ash, abus em alt r e yst, s tera a ny wa nt rtion, modific tion, or used in a y not i ended as desc ibed
in this manual.
* The specifications and design are subject to change without notice.
Please contact your Topeak dealer with any questions.
For USA customer service, call: 1-800-250-3068
www.topeak.com
Blinking
off
Blink
Sequence
0.5W
Constant Power / mode button Bag Mounting Clip
Mounting Hook
Low Battery /
charge indicator
Rubber StrapsUSB-Micro USB Cable
Copyright © Topeak, Inc M-. 2015 TMS080-GB 11/15
MOUNTING ON SEATPOST
• Although light body is water-resistant (under normal weather conditions of
rain, etc.) never intentionally submerge it underwater.
WARNING
BATTERY CHARGING MOUNTING ON BAG
• The RedLite™ Mini USB Charge Indicator will be lit GREEN when charging. LED will
turn off when battery is fully charged.
• The RedLite™ Mini USB Charge Indicator will be lit RED when the remaining battery
power is low. Please charge the light as soon as possible.
• The RedLite™ Mini USB LED will not illuminate if the battery is faulty.
• Disconnect the Micro-USB cable from your computer port when the RedLite™ Mini
USB is removed.
• After RedLite™ Mini USB is fully charged, unplug the USB cable.
• Do not open light body.
• Li-ion battery may take 3 to 5 charging cycles to attain full capacity.
• Do not leave battery connected to charge source over 48 hours continuously.
• Charging with USB hub will take longer.
• After long periods of non-use, the battery will lose charge. Always charge the battery
fully before each use and storage.
• Maintain the battery by charging it every two months and storing it in a cool, dry
place to prevent from decreasing its lifespan.
• Safely and properly dispose of the old Li-ion batteries according to your local
regulations.
Standard charging time
3~4 hours (approx)
To computer USB port
or USB charger.
USB
Micro USB
Open Micro USB Port Cap
Micro USB Port Cap
Function : Blinking / 0.5W Constant / Blink Sequence
Burn Time : 6 hr / 2.5 hr / 15 hr
Luminous : 11 Lumens / 100 CD
Lamp : 3 super bright 0.2W red LEDs
Battery : 3.7V 330mAh Lithium Ion
Charge : USB power supply 5V 500mA
Weight : 22 g / 0.78 oz (light only)
Reserve Time: 0.5 hr
SPECIFICATION
X shaped Rubber
Strap should be
centered on
seatpost for
even tension.
REDLITE™ MINI USB
(ø25.4 ~ ø31.8 mm)
(ø31.8 ~ ø34.9 mm)
( mm)ø12 ~ ø17
Product Specifications
