Page 1/2
From the underside of the motherboard, position the Fastening Plate under the 1.
CPU position such that the four screw posts are inserted through the holes on
the motherboard.
From the topside of the motherboard, apply Thermal Heatsink Grease evenly to 2.
the surface of the CPU. Only apply as much grease as will be required to cover
the surface of the CPU once the heatsink has been installed, as the pressure
of the heatsink application will spread the grease.
Place the heatsink and fan over the CPU, aligning the four holes on the 3.
heatsink with the screw posts (see step #1).
Secure the heatsink and fan to the Fastening Plate, using the four spring 4.
screws.
Connect the 3-pin (TX3) connector (on the fan) to the appropriate connector on 5.
the motherboard.
1
2
3
4
5
Technical Support
StarTech.comās lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever
need help with your product, visit www.startech.com/support and access our comprehensive selection of online tools, documenta-
tion, and downloads.
Warranty Information
This product is backed by a one year warranty. In addition, StarTech.com warrants its products against defects in materials and
workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for re-
pair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does
not warrant its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ofļ¬cers, directors, employees or agents) for
any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of proļ¬ts, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or
exclusions contained in this statement may not apply to you.
Fan Dimensions 70 x 70 x 10 mm
Heatsink Dimensions 107 x 71.8 x 25.5 mm
Bearing Type Dual Ball Bearing
Heatsink Base Material Copper
Fan Material Plastic
Rated Voltage 12 V
Noise Level <36 dB
Air Flow Rate 25.63 CFM
Connector Types 1 x TX3 Female
Best Fit Applications
Designed for AMD Socket AM2 series, typically found in
Server class systems with 1U low proļ¬le design:
AMD Opteron 1210HE - 1218 HE(to 65w)
AMD Sempron 2800+ - 3800+(to 62w)
AMD Sempron LE1100 - LE1250(to 45w)
Athlon 64 3000+ - 4000+(to 65w)
Athlon 64 LE1600 - LE1620(to 62w)
Athlon 64 p2-x2 3600+ - 5200+(to 65w)
Athlon X2 BE2300 -BE2400(to 45w)
Product Specifications
| Brand: | StarTech.com |
| Category: | Hardwarekoeling |
| Model: | FANK8AM21U |
