Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 08/15/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1xCaseFan

• 1x4-pinY-Cable

System Requirements

• 3-pinor4-pinfanheader

• Mountinglocationforcasefan

• Mountinghardware

FAN8025PWM / FAN9225PWM / FAN12025PWM

80mm/92mm/120mm Computer Case Fan with 4-pin PWM connector

How to Use

Theincluded4-pinY-Cablecanbeusedonsystemswithonlyoneavailable4-pinPWMFanHeadertoconnect

twodierentsystemfans.Connectthe4-pinfemaleconnectoronthecabletotheFanHeaderonthesystem

board,thenconnecta4-pinPWM-enabledfantothe4-pinmaleconnector(black).A3-pinor4-pinfancanbe

connectedtothe3-pinconnector(white).Thespeedofbothfanswillbecontrolledsimultaneously,basedonthe

PWMsignalfromthe4-pinconnector(black).

*actual product may vary from photos

Specications

FAN8025PWM FAN9225PWM FAN12025PWM

Bearing Type EverLubricateBearing

Air Flow Rate 9.74~25.02CFM 12.78~39.35CFM 33.20~78.41CFM

Noise Level <10dBA~28dBA <10dBA~25dBA <17.2dBA~39dBA

RPM 800~2500RPM 700~2200RPM 800~2200RPM

Material Plastic

MTBF 40,000hours

Operating Temperature -10°Cto70°C(14°Fto158°F)

Storage Temperature -20°Cto70°C(-4°Fto158°F)

Humidity 0~65%RH

Dimensions 80.0mmx80.0mmx

25.0mm

92.0mmx92.0mmx

25.0mm

120.0mmx120.0mmx

25.0mm

Weight 86g 96g 118g

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

Thismanualmaymakereferencetotrademarks,registeredtrademarks,andotherprotectednamesand/orsymbolsofthird-partycompaniesnotrelatedinanywayto

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,

oranendorsementoftheproduct(s)towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhere

inthebodyofthisdocument, StarTech.comherebyacknowledgesthatall trademarks,registeredtrademarks,servicemarks, andotherprotectednames and/or

symbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visit

www.startech.com/supportandaccessourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.During

thisperiod,theproductsmaybe returnedforrepair,orreplacementwithequivalentproducts atourdiscretion.Thewarrantycoversparts andlaborcostsonly.

StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrommisuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirector

indirect,special,punitive,incidental,consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseofthe

productexceedtheactualpricepaidfortheproduct.Somestatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,

thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.
