SPL MasterBay S Manual
Read below 📖 the manual in Italian for SPL MasterBay S (24 pages) in the Router category. This guide has been helpful for 5 people and has been rated 4.5 stars on average by 2 users
Page 1/24
Manual
Central analog interface to interconnect and manage hardware processors
MasterBay S
Model 1150
2MasterBay S
Content
Manual MasterBay S 4
Declaration of CE Conformity 4
Notes on Environmental Protection 4
Contact 4
Symbols and Notes 5
Scope of Delivery and Packaging 5
Introduction 6
MasterBay S 6
Concept 7
Special Features 7
Features 7
Important Security Advices 8
Hook Up 9
Placement 9
Rack Mounting 9
Air Circulation 9
Before You Connect Power 9
Power Connection and Fuse 9
Signal Connections 9
Rear Panel – Switches and Connectors 10
On/Off Switch 10
GND Lift 10
TRS Sockets (1/4" stereo jacks) 10
XLR Sockets 10
Balanced Connections 10
Unbalanced connections (TS and RCA connectors) 10
Main In 11
Rec Out 11
Monitor Out 11
DAW Return 11
Insert Send 1-4 11
Insert Return 1-4 11
Metering 11
Rear Panel – Wiring Diagram 12
Rear Panel – Wiring Diagram with M/S Master 13
M/S processing with the MasterBayS and M/S Master 13
3
MasterBay S
Content
Control Elements 14
Trim 14
Input Trim 14
Inserts 1-4, Swap 3›2 14
All Inserts Bypass 14
Insert Trim L and R 15
Trim L/R 15
Parallel Mix 15
Mix 15
Master Fader 16
Fader 16
DAW Return 16
Loudness Compensation 16
Compensation Level 16
Meters Follow 17
Auto Bypass 17
Bypass Period 17
I/O Compare 17
Specifications 18
Inputs & Outputs 18
Input Impedance 18
Output Impedance 18
Volume Control Ranges 18
Measurements 18
Power Supply 18
Dimensions & Weight 18
Copy Master: Recall Settings 19
Block Diagramm 20
Block Diagramm Insert-Matrix 21
Notes 22
