Blustream CMX88AB Manual
Read below 📖 the manual in Italian for Blustream CMX88AB (18 pages) in the Router category. This guide has been helpful for 7 people and has been rated 4.5 stars on average by 2 users
Page 1/18
CMX88AB
User Manual
CMX88AB USER MANUAL
02 www.blustream.co.uk
Surge protection device
recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. Use
of surge protection systems is highly
recommended in order to protect and
extend the life of your equipment.
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions care-
fully before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
Introduction 03
Features 03
Panel Descriptions 04
Control Ports 05
Matrix Front Panel Controls 06
Infrared Control 06
Infrared Remote Control 07
Audio Breakout 08
Automatic Video Resolution Conversion 08
Adjusting EDID Settings 08
Application Diagram 09
Specifications 10
Package Contents 10
Maintenance 10
RS-232 and Telnet Commands 11-12
Infrared Commands 13-15
Web Browser Interface 16
PC Configuration Soware 16
CMX88AB USER MANUAL
03
contact support@blustream.co.uk / support@blustream.com.au
Our Contractor CMX88AB 4K HDMI Matrix oers unprecedented
performance and value for the custom installation market. The
CMX88AB supports HDMI2.0 with HDCP2.2, allowing distribution of
eight HDMI sources to eight displays. This enables all sources to be
viewed as required within a matrix configuration. The unit transmits
all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 8-Way
matrix also includes audio breakout, EDID management and a web
browser interface module for control and configuration of the matrix.
Introduction
FEATURES:
• Features 8x HDMI inputs which can be independently routed to 8x HDMI outputs
• Supports 4K UHD video including HDR (up to 4K @60Hz 4:4:4)
• Independent video down conversion on all HDMI outputs allowing a display only capable of supporting
lower 4K video resolutions (4K 60Hz 4:2:0) to receive 4K 60Hz 4:4:4 video content while still showing
maximum original 4K UHD resolution on remaining outputs
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and
DTS-HD Master Audio transmission
• HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently
• Web interface module for control and configuration of the Matrix
• Control via front panel, IR, RS-232 & TCP/IP
• 3rd party drivers available for major home control brands
• Advanced EDID management
• HDCP 2.2 compliant
