page 1 / 3 sonel.com
Leakage current digital clamp meter
CMP-100
index: WMGBCMP100
Robust design
With the help of the latest tech-
nologies, a compact instrument
for working in the toughest con-
ditions has been created. The rub-
ber housing protects the device
against accidental damage.
Modern clamp
The appropriate shape means
easier access in hard to reach and
tight places.
Measurement of
very low currents
Measurement resolution of 1 μA,
very high sensitivity and accu-
racy are undoubted advantages
ofthemeter.
Visibility in any conditions
Darkness in the workplace is not
a problem thanks to the built-in
flashlight.
Low-pass lter
The low-pass lter minimizes sig-
nals with frequencies above the
cutoff frequency, reducing their
impact on the measurement result.
page 2 / 3 sonel.com
Measurement of load imbalance current
Measurement of differential current
Measurement of this component of the re-
sidual current that ows to ground bypass-
ing the PE lead
Leakage current measurement
page 3 / 3 sonel.com
m.v. - measured value
Technical specications
Measurement functions Range Resolution Accuracy
±(% m.v. + digits)
AC current up to 100,0 A from ±(1.0% m.v. + 5 digits)from 1 μA
Basic features
Counting 6.000 digits
HOLD
Manual range selection
Advanced features
Low-pass lter
Peak
TRMS measurement
Other features
Auto-off
Battery indication
Integrated flashlight
Display
Type segment-based LCD, 4 digits
Safety and conditions for use
Measuring category (EN 61010) CAT III 300 V
CAT II 600 V
Ingress protection IP30
Dimensions 234 x 82 x 46 mm 9.2” x 3.2” x 1.8”
|
Operating temperature 5...40ºC 41...104°F|
Storage temperature -20…+60ºC -4...140°F|
AC-16 line splitter
(facilitates current
measurements)
WAADAAC16
Factory calibra-
tion certicate
Calibration cer-
ticate with
accreditation
M-13 carrying case
WAFUTM13
3x LR03 AAA
1.5 V battery Basic case
Standard accessories
Optional accessories
