User Manual
8 Port Full HD Multiviewer Real-Time USB/KVM Switch
HDMV-8X
View up to eight different HD digital video sources on one
display device simultaneously
Made in U. S.A .1-80 0-AVI-2131www.Smar t AVI.com
TABLE OF CONTENTS
WHAT’S IN THE BOX 2
FRONT AND BOX 2
ACCESSORIES 2
SPECIFICATIONS 3
INTRODUCTION 3
FEATURES 3
PANEL LAYOUT 4
CONNECTING THE BOX 4
APPLICATION DIAGRAM 4
AVAILABLE CONFIGURATIONS 5
COMMAND SET 7
LIMITED WARRANTY STATEMENT 8
2
WHAT’S IN THE BOX
PART NO. Q-TY DESCRIPTION
SM-HDMV-8X 1 8-Port HDMI, USB Real-Time Multiviewer and KVM switch
1 Power Cord
FRONT AND BACK
Figure 2-1
ACCESSORIES
CONTROLLING THE MULTIVIEWER
VIA ETHERNET
The SMTCP-2 TCP/IP control module
is available from smartavi.com
ATTACHING A DVI-D DEVICE
An inexpensive HDMI to DVI-D adapter
will enable you to input or output your
signals to DVI-D devices
Table 3-1
3
VIDEO
Video Bandwidth Single-link 340MHz [10.2Gbps]
Resolution HDTV 480i,480p,720i,720p,1080i,1080p
PC Resolution 800 x 600 up to 1920 x 1200
Input Video Signal 1.2 volts
Input DDC Signal 5 volts
Single Link Range 1080p
Format HDMI 1.4
DVI Compliance Single-link DVI-D 2.0
HDCP Compliance 1.0/2.0
Video Bandwidth Single-link 340MHz [10.2Gbps]
Input Interface (4) HDMI
Output Interface HDMI
Connector Type A [19-pin female]
USB
Input USB 2.0, 1.1, and 1.0
Input Interface (4) USB Type B
Keyboard & Mouse USB 1.0 (Type A)
CONTROL
Front Panel Tact Switches
RS-232 DB9 (female)
OTHER
Power Internal 100-240 VAC
Dimensions 17” W x 1.7” H x 10.2” D
Weight 4.05 lbs.
Approvals UL, CE, ROHS Compliant
Operating Temperature +23 to +95°F (-5 to +35°C)
Storage Temperature -4 to 185°F (-20 to 85°C)
Humidity Up to 90% (No Condensation)
specifications
INTRODUCTION
The HDMV-8X allows you to view up to eight different high definition video sources simultaneously on one
display device. Connections to video sources are managed via HDMI connectors. Use this device to simplify
management of multiple sources by controlling them all through a single display using the front panel, RS-232,
and either through TCP-IP or the optional KVM.
Features
• View up to eight computers (8x) on a single monitor at the press of a button
• On-screen display (OSD) makes setup and switching easy
• Change views by pressing the Control Panel switches, RS-232, USB keyboard, or through LAN depending on
your model
• Display each computer with clean and crisp high-resolution video
• Supports HD resolutions up to 1920x1080p
• Delivers uncompressed digital video with zero signal loss
• HDCP and HDMI 1.4 compliant
• Supports EDID for total control of compliant displays
• Outputs HDMI up to 20 feet
