What’s in the box
Temperature Sensor
Installation Guide
Tools required Overview
Plan the installation
Example of installation
Install the Temperature Sensor
After determining the location, use the temperature sensor as
a template and mark the hull for the screws pilot hole. Route
the Temperature sensor and cable to the mounting location. If
routing through the transom, drill a 3/4” hole to accommodate
the Temperature Module.
Attach the Temperature sensor to the hull with one #8 stainless
steel screw and seal the screw (not included) with the below-
waterline sealant compound.
Screwdriver
Drill with 3 mm (1/8” ) and 19 mm
(3/4”) drill bit
1 #8 Stainless steel screw 19 mm
(3/4” ) long
High quality marine grade above/
below waterline caulking compound
The Temperature Sensor converts analog temperature data to
NMEA 2000 data format.
!You should read all of the installation instructions
before proceeding. Decide where to install all components
before drilling any holes in your vessel.
!
Make sure the Processing unit is inboard and not left
exposed on the open transom.
Other parts required
Temperature Sensor
NMEA 2000 T-Joiner
A Temperature sensor
B Processing unit
C NMEA 2000 connector
A Temperature sensor
B Processing unit
C NMEA 2000 CAN bus backbone
D Livewell
The temperature sensor can be mounted in any location where
you want temperature to be monitored. The most common
applications are transom mounts — to measure surface water
temperature — or in a livewell (when mounting in livewell,
mount as far from pump as possible).
Transom view
Livewell mount
38 mm (1.5”)
10 mm (0.4”) 6 mm (0,2”)
A
B
C
46 cm
(18”)
3 m
(10’)
Dimensions
Connect the Temperature Sensor to the network
A Temperature sensor cable 3 m (10 ft)
B Temperature Sensor
C NMEA 2000 CAN bus backbone
D 12 V DC Power supply. Connect via a switch and 5 amp
fuse Specications
Temperature Range between -20 and 80 degrees Celsius.
PGNs transmitted
59392 – ISO Acknowledgment
60928 – ISO Address Claim
126996 – Product Information
65285 - Temperature with Instance
A
A
B
B
C
C
D
D

Product Specifications

Brand: Simrad
Category: Not categorized
Model: Temperature Sensor
