Page 1/16
FONO MCMK4
Input loading DIP switch settings*
(located on rear panel):
LOADING RESISTANCE
1 and 2 o = 400Ω
1 on = 100Ω
2 on = 150Ω
1 and 2 on = 70Ω
CAPACITANCE
3 oîź· = 1000pF
3 on = 4300pF
GAIN
4 oîź· = 63.5dB
4 on = 69.5dB
TURNTABLE EARTH: If the turntable or tonearm
has a separate signal earth connection,
this should be connected to the turntable
earth terminal on the back of the unit.
OUTPUT: Connect the output socket of the
Fono to the line input on the amplier.
Please note: If you have an integrated
ampliîźşer with built in phono stage, DO
NOT connect the Fono to this input.
POWERING UP
The Fono MC is turned on by pressing the
on-o button located on the front. When the
unit is active the Rega logo will glow RED.
WARNING: We advise you to turn the Fono
on rst followed by the amplier. This
is because the power surge in the Fono
could cause an audible power on “thump”
which may distress the speakers.
METHOD OF CONNECTION
INPUT: Connect the tonearm leads and
earth (if used) to the input socket and to the
earth terminal on the back of the Fono.
1. INPUT
2. OUTPUT
3. TURNTABLE EARTH
4. AC SOCKET
1 2 3 4
OFF
ON
www.rega.co.ukEN
www.rega.co.ukFR
RĂ©glage du commutateur DIP charge
d’entrée (situé sur le panneau arrière):
RĂ©sistance charge
1 et 2 éteints (o) = 400Ω
1 en marche (on) = 100Ω
2 en marche (on) = 150Ω
1 et 2 en marche (on) = 70Ω
Capacitance
3 Ă©teints (oîź·) = 1000pF
3 en marche (on) = 4300pF
Gain
4 Ă©teints (oîź·) = 63,5dB
4 en marche (on) = 69,5dB
TERRE PLATINE: Si la platine ou le bras
a une prise de terre signal séparée, elle
devrait être connectée à la borne de terre
de la platine à l’arrière de l’unité.
SORTIE: Connecter la prise de sortie du Fono
sur l’entrée de ligne de l’amplicateur.
Veuillez noter: Si vous possédez un
amplicateur intégré avec un phono intégré,
NE PAS connecter le Fono à cette entrée.
MISE EN MARCHE
Le Fono MC s’allume en appuyant sur le
bouton marche/arrêt (on/o) situé sur
le devant, lorsque l’unité est active le
logo Rega sera illuminé en ROUGE.
AVERTISSEMENT: Nous vous recommandons
d’allumer le Fono en premier suivi
de l’amplicateur. Ceci parce que la
surtension dans le Fono pourrait causer
une alimentation audible de « bruit sourd
» pouvant perturber les haut-parleurs.
MÉTHODE DE CONNEXION
ENTRÉE: Connecter les ls du bras et la
terre (si utilisée) à la prise d’entrée et à
la borne de terre à l’arrière du Fono.
1. ENTRÉE
2. SORTIE
3. TERRE PLATINE
4. PRISE CA
1 2 3 4
OFF
ON
