Planar UltraRes W Series RS232 User Manual
020 1421- -00B
User Manual
Planar® UltraResTM Series RS232W
URW105 | URW105-ERO-T
Planar UltraRes W Series RS232 User Manual
020 1421- -00B
Page | 2
Copyright © October by Planar Systems, Inc. 2023
All rights reserved.
This document may not be copied in any form without permission from Planar. Information in
this document is subject to change without notice.
Trademark Credits
Windowsâ„¢ is a trademark of Microsoft Corp.
Planar utilizes HDMI® standards in this product.
The terms HDMI, HDMI High-Denition Multimedia Interface, HDMI Trade dress and the HDMI
Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
All other companies are trademarks or registered trademarks of their respective companies.
Disclaimer
The information contained in this document is subject to change without notice. Planar Systems,
Inc. makes no warranty of any kind with regard to this material. While every precaution has
been taken in the preparation of this manual, the Company shall not be liable for errors or
omissions contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
Warranty and Service Plans
Planar warranty and service plans will help you maximize your investment by providing great
support, display uptime, and performance optimization. From post-sale technical support, to a
full suite of depot services, our services are performed by trained employees. When you
purchase a Planar product, you get more than a display; you get the service and support you
need to maximize your investment. To find the latest warranty and service information regarding
your Planar product, please visit
http://www.planar.com/support
RoHS Compliance Statement
The Planar UltraRes W Series is fully RoHS Compliant.
Part Number: - - 020 1421 00B
Planar UltraRes W Series RS232 User Manual
020 1421- -00B
Page | 3
Table of Contents
RS232 Communication ................................................................................................. 4
1. Applicable Models ................................................................................................................ 4
2. RS232 Setup ....................................................................................................................... 4
3. Connecting the RS232 Cable .............................................................................................. 5
4. RS232 Command Protocol .................................................................................................. 6
4.1 Command Structure ............................................................................................ 6
4.2 Protocol Encoding ............................................................................................... 7
4.3 ples Exam ............................................................................................................. 7
5. RS232 Codes ...................................................................................................................... 9
5.1 Current Zone Layout .......................................................................................... 34
5.2 Key .................................................................................................................... 35
5.3 Timezone ........................................................................................................... 37
6. Sending RS232 Commands Via Ethernet .........................................................................41
6.1 Sending RS232 Commands Via SSH ...............................................................42
