Quick Start Guide
Planar UltraRes L Series Displays
Read this Document Before Unpacking!
Planar UltraRes L Series Displays Installation Process
Package Contents
Part
Description
Number
Left mount bar
Provides left structure for
LED columns to wall or
rolling stand.
2
Right mount
bar
Provides right structure for
LED columns to wall or
rolling stand.
2
LED columns
Provides mounting structure
for LED modules and
precision surfaces and
features for alignment,
labeled 1 through 5.
Note: All columns are
mechanically or electrically
dierent and are installed in
order. The installation
positions cannot be
swapped.
Product
dependent
(4, 5, or 6)
Left
electronics
Provides electronic functions
for the display.
1
Planar is a trademark of Planar Systems, Inc.
All other trademarks and service marks are the property of their holders.
Copyright© 2023 Planar Systems, Inc. All rights reserved.
This document may not be copied in any form without permission from Planar.
Information in this document is subject to change without notice. 11/23
www.planar.com
008 0229 00D- -
Page | 3
Quick Start Guide
Planar UltraRes L Series Displays
Part
Description
Number
Right
electronics
Provide electronic functions
for the display.
1
Left front
cover, comes
attached to
above left
electronics
Provides front cover for left
electronics and holds screen
bottom touch sensor
electronics.
1
Right front
cover, comes
attached to
above right
electronics
Provides front cover for right
electronics and holds display
bottom touch sensor
electronics.
1
Left side trim
Provide display trim on left
side and holds screen left
side touch sensor
electronics.
1
Right side trim
Provide display trim on right
side and holds screen right
side touch sensor
electronics.
1
Top left trim
Provide display trim on top
left side and holds display
top left touch sensor
electronics.
1
Top right trim
Provide display trim on top
right side and holds display
top right touch sensor
electronics.
1
