Page 1/8
© 08/2012 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
All installation work must be performed by a qualied professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Compatible with these double DIN devices
Double DIN Navigation
Nissan N400 2010->
Opel Movano 2010->
Renault Master III 2010->
Installation Manual
Double DIN Kit
colour: black part-no.
2-DIN 381250-15-x
2-DIN with pocket 281250-15-x
1
2
4
3
4
• (1) facia plate
• (2) metal frame right
• (3) metal frame left
• (4) at headed screw
pocket (only 281250-15-x)
1. Sample dashboard photo
with 1-DIN or OEM radio
Remove radio with relase keys
(unplug all connectors carefully
2. Remove 2 screws at the
left side beside the shift knob
3. Remove 2 screws at the
right side beside the
cup holder unit
4. Pull panel with shift knob
towards your direction.
Remove 4 screws (see arrows)
