Page 1/4
1
© 06/2009 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Compatible with these Pioneer double DIN devices
Pioneer Navigation
• Hyundai i20
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
Rubber-Touch: 291143-20
Silver: 281143-20s
Double DIN Kit contents
• (1) Side Panels (left / right)
• (2) Facia Plate
Installation Manual Double DIN Kit Hyundai i20
1. Unclip the Hyundai i20
OEM panel and remove it.
Remove the OEM-Radio.
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
2. Mount the the side panels to the
facia plate:
The panel marked with a „L“ is for
the left side, the panel marked
with a „R“ is for the right side.
3. Fix the Double DIN Navigation
with the Mounting Frame.
Connect all required circuit points
and place the Double DIN Navi
gation with the mounting frame
on the dashboard.
4. Place the Hyundai OEM panel on
the dash board
