Page 1/4
Ford Fiesta VI
Ford Focus III
Subwoofer Installation
Manual
Plug’n Play subwoofer
connection cable.
CA- -SUB-FOR.001AW
Ford Fiesta
Remove the following parts
using the correct tools :
- Info display surrounding
- Radio (2 screws &
2 bolts)
- Gearshift surrounding
- Right dashboard trim
- Right door sill
Ford Focus
Remove the following parts
using the correct tools :
- Radio (2 screws @ bottom)
- Gearshift surrounding
- Glove box
- Cup holders center console
- Richt door sill
Route the power cable to the
12volt plug in the center
console via the removed side
panel.
Take the remote control and
put it in the glove box.
Route the cable from there
behind the glove box, where
it meets the subwoofer cable.
Connect this piece of the
cable between the OEM
radio and the car connector.
CarRadio
Undo the 12volt plug and
connect to the power terminals.
Then make the second
connection back to the 12volt
plug.
Yellow cable = brown/red
Black cable = blue/black
Remote control
