© 12/2008 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Compatible with these Pioneer double DIN devices
Pioneer Navigation
Installation Manual
Double DIN Kit
• Seat Leon (1P) 2005
Double DIN Set contents
• (1) Metal Frame
• (2) Installation Kit
• (3) Facia Plate
• (4) Trim Frame
Colour Part-No. Part-No. Standard Rubber-Touch
anthracite 381328-05 391328-05
black 381328-55 391328-55
3. Insert 4 radio release keys into slots
on the top and bottom of the radio
(see arrows)
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
1. Vehicle with OEM head unit.
Mount the metal brackets to the
double DIN head unit.
The position of the copper
coloured holder can be adjusted
to your needs for perfect fit.
(see sample)
(sample photo) (sample photo)
4. Pull out the OEM head unit.
5. Place the facia plate on the
dashboard.
Push the Metal Frame into the
facia plate.
Connect all required circuit
points and push the double
DIN head unit in the metal
frame until it snaps in.
Place the trim frame.
Reinstall everything in reverse
order to finish installation.
