© 12/2008 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Compatible with these Pioneer double DIN devices
Pioneer Navigation
• Audi A3 2003
• Audi A3 2007
Double DIN Kit contents
• (1) Metal Frame
• (2) Facia Plate
Installation Kit (3)
Trim Frame (4)
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
Standard: 381320-14
Rubber-Touch: 391320-14
Installation Manual Double DIN Kit 381320-14
1. „Audi Navigation Plus“
OEM head unit
2. Use 4 radio release keys to
dismount the OEM radio.
5. Connect alle required circuit
points and push the double DIN
head unit until it snaps in.
Place the trim frame to finish
installation.
3. Remove the OEM radio.
Mount the metal brackets with
the double DIN head unit
The position of the copper colou-
red holder can be adjusted to your
needs for perfect fit. (see sample)
4. Push the metal frame into the
facia plate
Place it on the dashboard. Press
the facia plate, until it snaps in.
