Page 1/4
Compatible with these Pioneer double DIN devices
Pioneer Navigation
Installation Manual
Double DIN Kit
Standard: 381275-02
Rubber-Touch: 391275-02
• SsangYong Rexton II 2006
Double DIN Set contents
• (1) Metal Frame
• (2) Installation Kit • (3) Facia Plate / Mounting frame
© 12/2008 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Installation Manual Double DIN Kit 381275-02 / 391275-02
3. Remove the original bracket.
This is tighten by screws.
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
1. Remove the panel under the
climate control panel.
Mount the metal brackets to the
double DIN head unit.
The position of the copper
coloured holder can be adjusted
to your needs for perfect fit.
(see sample)
(sample photo) (sample photo)
2. Remove the speaker grill on top of
the dashboard. Remove the two
which have become visible.
Remove the front panel.
4. Place the 2-Din metal bracket
and tighten the bracket by
screws.
5. Place the headunit and replace
all the panels.
