Installation Manual
Double DIN Kit
Colour Part-No.:
Standard
Part-No.:
Rubber-Touch
black 381114-19-B 391114-19-B
silver 381114-19-S 391114-19-S
Ford C-MAX 2007->
Ford Focus 2007->
Ford Galaxy 2007->
Ford Mondeo 2007->
Ford S-MAX 2007->
with Ford OEM-Radio:
6000 CD / Audio SONY 6CD / Travel Pilot X
2. Remove the four screws
Remove the OEM-Radio
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
1. Unclip the frame surrounding
the OEM-Radio and remove it
Mount the metal brackets to the
double DIN head unit.
The position of the copper
coloured holder can be adjusted
to your needs for perfect fit.
(see sample)
(sample photo) (sample photo)
3. Push the head unit with the
mounted metal brackets into the
metal frame, until it snaps in
Place the mounting frame
on the dashboard and fix it
with the 4 original screws
Connect all required circuit points
and push the double DIN head
unit into the mounting frame
until it snaps in
Place the facia plate
Place the frame surrounding the
radio to finish installation
