POWERFUL 24VOLT CLASS D AMPLIFIERS
SUITABLE FOR 24VOLT SYSTEMS
Model: ZT6004R / ZT15001
• - powers on the amp when audio signal is suppliedHigh Level Auto-Turn On
• - compatible with aftermarket/original source unitsOEM Connection Ready
• Integrated Fan - regulates temp. for sustained performance (ZT15001 only)
• - control bass/gain with included ZRBC Remote Ready
• - versatile connectivity to suit any vehicleHigh & Low Level Inputs
• - enables maximum current supplyHeavy Duty Connector Block
• - protection against thermal damage, 4-Way Protected Circuit
reversed power, speaker polarity and low voltage
SPECIFICATIONS
All specications subject to change without notice.
ZT
24VOLT
© 2023 Phoenix Gold | www.phoenixgold.com
ZT6004R / ZT15001 - ZT-Series Ampliers
Specications ZT6004R ZT15001
Class Class D Class D
Channels 4 1
Frequency Response 12Hz – 22kHz 20Hz – 400Hz
RMS Power Rating (1Ω): N/A 1 x 1500W
RMS Power Rating (2Ω): 4 x 175W 1 x 1150W
RMS Power Rating (4Ω): 4 x 105W
2 x 350W Bridged 1 x 650W
Signal to Noise Ratio (SNR) (Full Power) -90dB -74dB
Total Harmonic Distortion (THD) <1% <1%
Low Pass Filter (LPF) 50Hz – 400Hz (12dB/Oct) 50 – 250Hz (24dB/Oct)
High Pass Filter (HPF) 50Hz – 400Hz (12dB/Oct) N/A
Subsonic N/A 10Hz – 55Hz (24dB/Oct)
Bass Boost @ 45Hz 0 – +18dB 0 – +18dB
Crosstalk -60dB N/A
Input Sensitivity 0.25V – 9.8V 0.29V – 9.3V
Fuses 2 x 20A N/A
Remote Yes (Included) Yes (Included)
High-level Input Via RCA Yes Yes
Auto Turn-on Yes Yes
Phase Control N/A 0° - 180°
Operating Voltage 20V – 32V 17V – 31V
Idle Current 0.55A 1.04A
Current Draw (Max) 34A 87A
Total Efciency (4Ω) 88% 88%
Power Terminal 20mm² 20mm²
Speaker Terminal 4mm² 20mm²
Dimensions (LxWxH) 254 x 160 x 48.3mm 334 x 160 x 48.3mm
Weight 1.76 kg 2.6 kg
© 2023 Phoenix Gold | www.phoenixgold.com
ZT6004R / ZT15001 - ZT-Series Ampliers
Installation Warnings
1. Ensure the +12V lead is disconnected from the battery before you
connect any new equipment
2. Ensure that the amplier mounting location and holes will not interfere
with the petrol tank, brake lines or electrical wiring.
3. Ensure the amplier is securely fastened to the vehicle to prevent the
amplier from moving and causing damage in the event of an
accident.
4. Ensure all wiring is protected from sharp objects and pinching or
crushing, which could damage the audio system.
5. Ensure the mounting location has sufcient air ow around the
amplier. If the amplier is mounted in an enclosed space, a 3” fan
with ducting should be used to assist with cooling.
6. Ensure the minimum recommended gauge wire/cable or larger for
all amplier connections.
7. Appropriate mounting is essential for the prolonged life expectancy of
any amplier. Select a location that protects from moisture. Keep in
mind that an amplier should never be mounted upside down. Up
side-down mounting will compromise heat dissipation through the heat
sink and could engage the thermal protection circuit.
Disclaimer
Ensure your safety and the well-being of those around you by following these essential guidelines:
• Keep all product materials and packaging away from children, pets, or anyone at risk of suffocation.
• Exposure to noise levels above 85 dB can cause permanent hearing damage.
• Extreme sound frequencies reduce perception abilities that are essential in road trafc conditions; do not let loud
volumes distract from being mindful behind the wheel.
• Phoenix Gold takes no responsibility for any physical harm or damage caused by improper use of their products.
• Ensure that all metals and raw materials are disposed of in accordance with local regulations and environmental
Warranty
Phoenix Gold products come with a limited warranty and are covered by our regional distribution partners and their
terms and conditions. You can nd out more information by contacting your local retailer or distributor.
