MAX
INSTALLATION MANUAL ZDAPV1
Step by step Instruction
Notes
1
Connect multiconnector to amplifier & Connect the Yellow wire to +12 Volt and black cable to GND
20-way black connector
2
Connect the ISO connector together firmly
These terminal can also be connected to
battery and ground for better performance
3
Locate the Original amplifier under right from seat and disconnect the Original wires from the amplifier and
connect the leads from the amp to the amplifier and the other end to the original connector
4
Now start the system and upload the preferred Volvo setup file from Phoenix gold EU Website
https://phoenixgold-eu.com/downloads/
1.
2.
3.
4.
Thank you for buying this upgrade kit. We think you
will love this product and we hope that you will enjoy
the extra performance this will give you!"
Installation should take about 10min please mount
amplifier as you see fit but we recommend it to be
mounted in back of the car. No cutting o any wires
just plug connectors in and load the software and you
are good to GO!"
PS. If you wish to give the optimal performance to the amplifier
you can connect thicker cables on the +12V and GND connectors
for the amp. From the battery. This will improve performance
further.

Product Specifications

Brand: Phoenix Gold
Category: Not categorized
Model: ZDAPV1
