Page 1/4
USB 3.0 Dual
Display Docking Station
Quick Installation Guide
Installing the Driver
CAUTION: DO NOT connect the docking to a computer before Station
installing the provided driver.
* The following strings and screenshots may vary slightly from each
operating system.
* Windows® 7 must be upgraded to SP1 or later.
Windows ®
OS
1. Please download the driver for your device: originstorage.com/
origin-drivers.
2. Click execute the installer program. for the Run Setup.exe to Wait
program to the install drivers.
3. Click to complete the installation. Finish
NOTE:
a. If the AutoPlay does not start automatically, locate and double-
click on setup. the Setup.exe in the the le driver folder to launch
b. Enter the administrator password and click Yes, if a User Account
Control dialog box is prompted.
c. For some Windows Operating Systems, the driver will automatically
be installed. If you need to install the driver manually, follow the
instructions above.
Mac OS®
1. Please download the driver for your device: originstorage.com/
origin-drivers.
2. If the is prompted, click to start the License agreement Continue
driver installation.
3. Click to nish installing the software. Restart
Making the Connection
1. Connect the Docking Station to a DVI monitor (Dual Display
Docking Station to a HDMI or/and DVI monitor) and a computer.
The screen may temporarily go black or ash during this process.
2. Connect the USB peripherals, such as Ethernet, speaker and
microphone to the corresponding connectors.
Multi-monitor Conguration
An extra DVI monitor can be connected through the Docking
Station (HDMI and DVI monitors for Dual Display Docking
Station) if one monitor is already connected to the PC directly.
Once the extra monitor is connected, it can be congured to use
either “ ”, “ ” or be the Mirror mode Extended mode Primary
display.
Position the mouse anywhere on the , right-Windows Desktop
click and select on WindowsDisplay Settings
®
10, Screen
Resolution on Windows
®
7/ Windows
®
8/ Windows
®
8.1,
Personalize > Display Settings on Windows
®
Vista or
Properties > Settings on Windows
®
XP.
Alternatively, click utility icon
in the Windows System Tray,
and then select or .DisplayLink Manager Video Setup
Incorporates HDMI
®
technology.
This Quick Installation Guide describes only the basic instructions
on installation. For more information,
please refer to the User’s
Manual on the provided CD-ROM
.
Dual Display
Docking Station
Single Display
Docking Station
Product Specifications
| Brand: | Origin Storage |
| Category: | Other computer accessories |
| Model: | OSDOCK-USB3 |
