Page 1/12
Owner’s Manual
Havis Docking Station for
Getac S410 Notebooks
www.havis.com
1-800-524-9900
DS-GTC-611
DS-GTC-611-3
DS-GTC-613
DS-GTC-613-3
DS-GTC-614
DS-GTC-614-3
DS-GTC-615
DS-GTC-615-3
DS-GTC-617
DS-GTC-617-3
DS-GTC-618
DS-GTC-618-3
DS-GTC-610 Series
DS-GTC-611
DS-GTC-611-3
DS-GTC-613
DS-GTC-613-3
DS-GTC-614
DS-GTC-614-3
DS-GTC-615
DS-GTC-615-3
DS-GTC-617
DS-GTC-617-3
DS-GTC-618
DS-GTC-618-3
Before Beginning (Original Instructions)
2
• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the DS-GTC-610 Series Docking Station for
Getac S410 Notebooks.
For questions regarding the set-up of your DS-GTC-610 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Owner’s Manual applies to the following Part Numbers:
• FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY
(DS-GTC-615/615-3/617/617-3/618/618-3) REFER TO THE SUPPLIED GETAC
POWER SUPPLY REFERENCE GUIDE.
• WHEN NOTEBOOK IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN
0°C to 50°C (32°F to 122°F).
PLEASE REFER TO GETAC S410 OWNER’S MANUAL FOR MORE INFORMATION.
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
• DO NOT STORE, INSTALL, OR OPERATE THE DOCKING STATION WHERE WATER, MOISTURE,
STEAM, DUST, ETC. ARE PRESENT
• DO NOT DOCK OR UNDOCK YOUR COMPUTER UNLESS IT IS POWERED OFF. DOCKING OR
UNDOCKING WITH YOUR COMPUTER IN ON, STANDBY, HIBERNATION, OR SLEEP MODES
CAN CAUSE PERMANENT DAMAGE.
• FOR THE DS-GTC-611, DS-GTC-611-3, DS-GTC-612, DS-GTC-612-3, DS-GTC-615,
DS-GTC-615-3, DS-GTC-617, & DS-GTC-617-3 DOCKING STATIONS:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: This product requires
a certied, automotive grade, Getac approved 120W power source rated for a
continuous, regulated 19VDC output (Havis Part Number LPS-140 or equivalent).
Failure to comply with this requirement will cause product damage that is NOT
repairable and is NOT covered under warranty.
• FOR THE DS-GTC-613, DS-GTC-613-3, DS-GTC-618, & DS-GTC-618-3 DOCKING STATIONS:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: The Getac S410 notebook
requires a certied, Getac approved power source rated for a continuous, regulated
19VDC output. Failure to comply with this requirement will cause product damage
that is NOT repairable and is NOT covered under warranty.
Related Products
Table of Contents
3
Specications
Parts Included
Port Replication Capability
Antenna Identication
Installation
Cable Management
Operation - Docking
Operation - Undocking
3
4
5
5
6
7
8
9
Specications
Power Supply Input 19V DC-In
Dimensions 2.4” ( 6.17 cm) H x 14.1” ( 35.7 cm ) W x 11.8” ( 30.0 cm ) D
Weight 5.1 lbs ( 2.3 kg )
Operating Environment -21° C to 60° C ( -6° F to 140°F )
Storage Environment -40° C to 85° C ( -40° F to 185° F )
• Do not place metal objects or containers of liquid on top of the Docking Station
• If a malfunction occurs, immediately unplug the Power Supply and remove the laptop
• Use only the specied Power Supply with this Docking Station(Part # LPS-140)
• Do not connect cables into ports other than what they are specied for
• Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F)
for a long period of time
Precautions
EC DECLARATION OF CONFORMITY in accordance with EN 50498
Manufacturers Name: Havis, Inc.
Manufacturers Address: 75 Jacksonville Road, Warminster, PA 18974 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Getac S410 Fully Rugged Convertible Notebook
Model: DS-GTC-61X, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
Automotive EMC Directive EN 50498:2010, Electromagnetic compatibility (EMC) -
2004/108/EC: Product family standard for aftermarket electronic equipment in vehicles
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
Supplementary Information:
The product herewith complies with the requirements of the Automotive EMC Directive 2004/108/EC, Annex I, 6.5, 6.6, 6.8,
and 6.9. This product requires the use of a recommended e-Marked automotive power supply when used within vehicles.
Warminster, PA, USA June 1, 2016 Bruce Jonik, Director of Engineering , Havis, Inc.
FCC 47CFR, Part 15 compliance: This is an FCC Class B device. Any changes or modications
to the model DS-GTC-61X not expressly approved by Havis, Inc. could void
the user's authority to operate this equipment.
