Page 1/8
Vehicle Dock
For Panasonic CF20 Laptop Computers
User Guide
www.gamberjohnson.com
©
Descripîon
Part Number
Dock for Panasonic
CF20 Laptop, NPT - -7300 0191 00
Dock for Panasonic
CF20 Laptop, DPT - -7300 0191 02
Dock for Panasonic
CF20 Laptop, NPT w/ Screen Lock - -7300 0191 20
Dock for Panasonic
CF20 Laptop, DPT w/ Screen Lock - -7300 0191 22
Cradle for Panasonic
CF20 Laptop - -7300 0190 00
Cradle for Panasonic
CF20 Laptop w/ Screen Lock - -7300 0190 10
Screen
Lock Module -7300 0192
General Instrucîons
POWER:
âąThe power input should be 15.6Vdc / 7.05 A. The dock is meant to operate on 14.5 Vdc to 16
Vdc. Use a recommended power supply for the dock. Panasonic recommends using a Lind
Auto Adapter (Lind part no: PA 1580-1745) for this dock.
WIRING:
âąGamber-Johnson does not recommend relying on a cigareîe socket adaptor for powering
vehicle docks. We recommend hard wiring using a good clean ground direct from the vehicle
battery (-) post, and (+) supply from a fused 12v locaîon also directly from the vehicle battery.
All Peripherals connecîng to the docking staîon should get power and ground from the same
locaîon as the dock.
âąVisit www.gamberjohnson.com for a copy of our general wiring and troubleshooîng guide.
SERVICING [ENTRETIEN]:
âąIf the dock does not work as intended, please contact Gamber-Johnson for troubleshooîng or
to schedule a service. [Si le dock ne foncî±onne pas comme prĂ©vu, contactez Gamber-Johnson
pour le dĂ©pannage ou pour planiî
er un service.]
âąServicing of the dock should be only done by authorized service center personnel.
Unauthorized servicing of the dock will void its warranty. [L'entreî±en du dock ne doit ĂȘtre
eî
ectuĂ© que par le personnel du centre de service autorisĂ©. Un entreî±en non autorisĂ© du dock
annulera sa garanî±e.]
EXTERNAL ANTENNA:
âąFor DPT (Dual Pass Thru) models, there is an opîon to turn oî
the external antenna. This
switch is located next to power port of the dock. Toggle the switch gently excess force might â
break the switch. Turning off the external antenna will let the computer use in-built antenna.
By default, the dock comes with the switch in ON posiîon.
Descripîon of Parts and Layout
Front View
Note: All pictures used in this guide are of Dual Pass Thru (DPT) with Screen Support vehicle dock
(Part no: - -22). However processes and informaîon relate to other variants of the same 7300 0191
dock menîoned in previous page.
Lock
Docking Connector Housing
with Guide Pins and Shuî©er
Cover
RF pass thru
connectors
Back Clamp
Guides (X3)
Screen Lock
Front Clamps (2)
Latch
Mounîng Plate
