Page 1/5
DELUXE GAMING CPU MOUNT
WITH SLIDING TRACK
MI-7172
Please scan this QR code
to visit the product page.
Thank you for choosing Mount-It
2
Mount-It!
Mount-It!
Mount and Accessories
4
• Partially install 2 Screws (#F) into the drilled locations, leaving a gap of approximately 1/10” (3mm)
between the desk and the bottom of the screw head. Place the Under Desk Mount (#B) over the two
screws and slide the mount so that the screws are resting in the smaller end of the keyhole slots.
Attach the Mount
Step 2
Step 3
• Hold the Under Desk Mount (#B) underneath the desk in the desired location. Ensure adequate depth
from the edges of the desk to accommodate the dimensions of your PC case. Using a pencil mark the
center of the smaller end of the 2 keyhole shaped screw slots as shown here. Remove the desk mount
and drill a hole in the marked location using a 1/8” (3mm) drill bit to a depth of 0.6” (16mm).
Prepare the Mounting Surface
Step 1
