Lindy 43341 Manual
Read below 📖 the manual in Italian for Lindy 43341 (8 pages) in the Cables for PCs and peripherals category. This guide has been helpful for 8 people and has been rated 4.5 stars on average by 2 users
Page 1/8

Part no.:
| DESCRIPTION
43341
1m USB Type C to DP 8K60 Adapter Cable
Connect a DP display to your computer´s USB Type C port
Connects a 4K or 8K DP display to a computer equipped with a USB Type C port
Supports DisplayPort resolutions up to 7680x4320@60Hz and 3840x2160@144Hz
Perfect for connecting Macbooks (incl. Apple M1), laptops and PCs to modern DP displays
Requires DisplayPort Alternate Mode support by the USB Port/Bus
2 year warranty
This Lindy USB Type C to DisplayPort 1.4 Adapter Cable with HDR allows users to easily add external video capabilities to a
computer featuring the USB Type C port with additional support for DisplayPort Alternate Mode. This DisplayPort connector of the
adapter cable can be directly connected to the DisplayPort display with the 1m cable allowing for additional exibility whenfl
positioning of the DP display - perfect for a simple and adaptable installation.
It supports video resolutions up to 7680x4320@60Hz and 3840x2160@144Hz, making it the ideal tool for 8K game streaming or
high resolution 8K video editing. Additional support for High Dynamic Range ensures video content can be seen with enhanced
brightness, superior contrasts and a much wider colour gamut for more lifelike colour. These cables are great for creating eye-
catching retail displays, innovative working environments or immersive video playback in sports bars and home cinema
installations, while support for uncompressed multi-channel audio allows for an impressive three-dimensional surround sound
performance to compliment detailed, clear video.
This cable is powered by the USB Bus, so no external power supply is needed and with ‘Plug and Play’ installation, this converter
cable can be installed into an AV system with minimum di culty, ideal for both professional and rst time users.ffi fi
•
•
•
•
•
| TECHNICAL DATA SHEET

Connectors
Connector A: USB Type C Male
Connector B: DisplayPort Male
Housing Material: USB C: ABS shell, DP: ABS shell
Connector Plating: Nickel plating
Pin Construction: Phosphor Copper
Pin Plating: Gold plating
Dimensions (approx.) WxDxH:
USB: 24.3x12.52x7mm (0.96x0.49x0.28in)
DP: 47.74x22.2x10mm (1.88x0.87x0.39in)
Cable construction
Length: 1m (3.28ft)
Standard: DP 1.4
Colour: Black
Type: Round
Jacket Diameter: 4.2mm (0.17in)
Jacket Material: PVC
Conductor Material: Tinned Copper
Conductor Gauge: 34AWG
Shielding: Copper Braid 85%
Speci cationsfi
Chipset: VL100
Supported Bandwidth: 32.4Gbps
Power Delivery: -
Maximum Resolution: 7680x4320@60Hz and 3840x2160@144Hz
Nominal Attenuation: 0.1MHz-6MHz<12DB
Minimum Bend Radius: 25.5mm (1in)
Operating Temperature: -20°C - 40°C (-4°F - 104°F)
Storage Temperature: -40°C - 80°C (-40°F - 80°F)
Miscellaneous
Packaging Type: Polybag
Warranty (Years): 2
Product Compliance: CE, FCC, RoHS, REACH, California Proposition 65
Purchasing Information
No.: 43341
EAN: 4002888433419
This product is available in different lengths
43341 - 1m (3.28ft)
43342 - 2m (6.56ft)
43343 - 3m (9.84ft)
•
•
•
•
•
•
•
◦
◦
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET

Artikelnr.:
| BESCHREIBUNG
43341
1m USB Typ C an DP 8K60 Adapterkabel
Zum Anschluss eines DisplayPort-Monitors an den USB Port Typ C
Verbindet einen 4K bzw. 8K-DisplayPort-Monitor mit dem USB-Anschluss Typ C des Computers
Unterstützt DisplayPort-Auflösungen bis 7680x4320@60Hz einschließlich 3840x2160@144Hz
Perfekt geeignet zum Anschluss von Macbooks (inkl. Apple M1), Laptops und PCs an moderne DP Displays
DisplayPort-Alternate-Mode-Unterstützung durch den USB Port/Bus erforderlich
2 Jahre Garantie, mehr über Garantiebedingungenhier
Dieses Lindy USB Typ C an DisplayPort 1.4 Adapterkabel mit HDR-Unterstützung ermöglicht Computernutzern durch den USB-
Anschluss Typ C mit DisplayPort-Alternate-Mode-Unterstützung Videofunktionen hinzuzufügen. Der DisplayPort-Stecker des
Adapterkabels kann direkt am DisplayPort-Monitor angeschlossen werden. Das 1m lange Kabel erlaubt - anders als bei
Verwendung einer Konverterbox - ein flexibles Aufstellen des Displays.
Das Kabel unterstützt Auflösungen bis 7680x4320@60Hz einschließlich 3840x2160@144Hz, dies macht es zur idealen
Systemkomponente für 8K-Spiele-Streaming oder hochau ösende 8K-Videobearbeitung.fl
Die zusätzliche Unterstützung für High-Dynamic Range (HDR) sorgt für eine Darstellung der Videoinhalte mit überragenden
Kontrasten, einem erweiterten Farbumfang und erhöhtem Detailreichtum - perfekt für auffallende Displays im Handel, innovative
Arbeitsumgebungen oder ein intensives Videoerlebnis in Sportbars oder im Home Cinema. Unkomprimiertes Mehrkanal-Audio
ermöglicht die Untermalung mit beeindruckendem 3D-Surround-Sound.
•
•
•
•
•
| TECHNICAL DATA SHEET
Product Specifications
Brand: | Lindy |
Category: | Cables for PCs and peripherals |
Model: | 43341 |
