Page 1/10
Part no.:
| DESCRIPTION
36469
15m Standard HDMI Cable, Black Line
HDMI Male to Male
Entry Level Standard HDMI 2.0 cable for home and small office applications
Supports UHD resolutions up to 4096x2160@30hz 4:4:4 8bit
Robust PVC housing, Nickel Connectors, 24k gold plated contacts
Triple shielded cable, corrosion resistant copper coated steel 28AWG conductors
10 year warranty
From the lines cable connectivity concept developed by Lindy, Black Line Standard HDMI cables are fully featured, entry level high
resolution connection solutions, perfect for home and small office use.
Black Line Standard HDMI cables feature triple shielded construction with 28AWG copper coated steel conductors for premium
performance and corrosion resistance. Nickel connectors and gold ashed contacts maintain signal integrity and reliability. fl
UHD resolutions up to 4K 4096x2160@30Hz 4:4:4 8bit are supported. Black Line HDMI cables are also capable of transmitting 32
channel audio and Dolby True HD.
The HDMI 2.0 speci cation is supported for 10.2Gbps bandwidth capacity in cable lengths up to 15m.fi
Black Line HDMI cables are available in lengths from 0.5m to 15m
•
•
•
•
•
| TECHNICAL DATA SHEET
Connectors
Connector A: HDMI Type A Male
Connector B: HDMI Type A Male
Housing Material: PVC
Connector Plating: Nickel
Pin Construction: Phosphor bronze
Pin Plating: Gold Flash
Dimensions (approx.) WxDxH: 19.2x34.1x10.6mm (0.76x1.34x0.42in)
Cable Construction
Length: 15m (49.21ft)
Standard: Standard HDMI
Colour: Black
Type: Round
Jacket Diameter: 7mm (0.27in)
Jacket Material: PVC
Conductor Material: Copper Coated Steel
Conductor Gauge: 28AWG
Shielding: Aluminum Foil
Speci cationsfi
Supported Bandwidth: 10.2Gbps
Maximum Resolution: 4096x2160@30Hz 4:4:4 8bit
Nominal Attenuation:300kHz-825MHz <5dB, 825MHz-2.475GHz <5dB, 2.475GHz-4.125GHz <12dB, 4.125GHz-5.1GHz
<20dB
Minimum Bend Radius: 70mm (2.75in)
Operating Temperature: -10°C - 80°C (14°F - 176°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
ATC Approved: No
Miscellaneous
Packaging Type: Polybag
Warranty (Years): 10
Product Compliance: RoHS, Reach, UL
Purchasing Information
No.: 36467
EAN: 4002888364683
This product is also available in otherlengths
36470 - 0.5m (1.64ft)
36471 - 1m (3.28ft)
36472 - 2m (6.56ft)
36473 - 3m (9.84ft)
36474 - 5m (16.44ft)
36467 - 7.5m (24.60ft)
36468 - 10m (32.80ft)
36469 - 15m (49.21ft)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
Artikelnr.:
| BESCHREIBUNG
36469
15 m Standard-HDMI-Kabel, schwarze Linie
HDMI Stecker auf Stecker
Standard-HDMI 2.0-Kabel für Einsteiger für Heim- und kleine Büroanwendungen
Unterstützt UHD-Auflösungen bis zu 4096x2160@30hz 4:4:4 8bit
Robustes PVC-Gehäuse, Nickel-Steckverbinder, 24k vergoldete Kontakte
Dreifach geschirmtes Kabel, korrosionsbeständige Leiter aus kupferbeschichtetem Stahl 28AWG
10 Jahre Garantie, mehr über Garantiebedingungenhier
Aus dem von Lindy entwickelten Cable Line - Konnektivitätskonzept sind Black Line Standard-HDMI-Kabel voll ausgestattete,
hochauflösende Verbindungslösungen der Einstiegsklasse, die sich perfekt für den Heim- und kleinen Bürogebrauch eignen.
Black Line Standard HDMI-Kabel verfügen über eine dreifach geschirmte Konstruktion mit 28AWG kupferbeschichteten
Stahlleitern für erstklassige Leistung und Korrosionsbeständigkeit. Nickel-Steckverbinder und vergoldete Kontakte gewährleisten
die Signalintegrität und -zuverlässigkeit.
UHD-Auflösungen bis zu 4K 4096x2160@30Hz 4:4:4 8bit werden unterstützt. Black Line HDMI-Kabelsind auch in der Lage, 32-
Kanal-Audio und Dolby True HD zu übertragen.
Die HDMI 2.0-Spezi kation wird für eine Bandbreitenkapazität von 10.2 Gbit/s in Kabellängen von bis zu 15 m unterstützt.fi
BlackLine HDMI-Kabel sind in Längen von 0,5 m bis 15 m erhältlich
•
•
•
•
•
| TECHNICAL DATA SHEET
Product Specifications
| Brand: | Lindy |
| Category: | Cables for PCs and peripherals |
| Model: | 36469 |
