Page 1/6

Sauter GmbH
Ziegelei 1
D-72336 Balingen
e-mail: info@kern-sohn.com
Phone : +49-[0]7433- 9933-0
Fax: +49-[0]7433- - 9933 149
Internet: www.sauter.eu
Instruction manual digital shore
hardness tester
SAUTER HD
Version 3.0
03/2020
GB
HD- -e- BA 2030
PROFESSIONAL MEASURING

2 - -e- HD BA 2030
GB
SAUTER HD
V. 3.0 03/2020
Instruction manual digital shore hardness tester
Thank you for purchasing the digital Shore hardness tester from SAUTER. We hope
you will be very satisfied with the high quality of the hardness tester and its
functionality. For any questions, wishes and suggestions we are at your disposal.
Table of contents:
1 Before commissioning .................................................................................. 3
2 General overview ........................................................................................... 3
3 Technical data ................................................................................................ 4
4 Measurement method .................................................................................... 4
5 Calibration check ........................................................................................... 6
6 Battery replacement ...................................................................................... 6
7 Important! ....................................................................................................... 6

HD- -e- 3 BA 2030
1 Before commissioning
Before putting the device into operation, check the delivery for any transport damage
to the packaging, the plastic case and the device itself. Should this be the case,
SAUTER must be contacted immediately.
2 General overview
The instrument was developed to determine the penetration hardness of various
materials such as foamed goods or hard plastics. Each type of hardness tester is
designed for a corresponding Shore hardness scale (i.e. A, D, O,) and shows the value
in the range from 0 to 100 on the respective scale.
• Type A - designed for soft vulcanized rubber, natural thermoplastic elastomers,
elastic polyacrylic and thermosetting plastics, wax, felt and leather.
• Type D - designed for hard rubber, thermoplastic elastomers, harder plastics
and moderately hard thermoplastics.
• Type O - designed for soft rubber, thermoplastic elastomers, very soft plastics
and thermoplastics, as well as for medium density braided textile fabrics.
The hardness tester is equipped with a special microprocessor controlled circuit LSI
as well as a quartz time base, which guarantees a precision measurement.
Digital display for precise readings without rates and errors.
Furthermore, the hardness tester has an interface for storing, printing and evaluating
data using optionally available software and an RS232C connection cable.
Automatic power o function to save energy.
a small test stand from the range of accessories allows to obtain high accuracy and
repeatability thanks to a constant measuring force, eliminating possible errors due to
dierent forces not acting axially.
