Page 1/12

Sauter GmbH
Ziegelei 1
D-72336 Balingen
E- -Mail: info@kern sohn.com
Tel. - - -0 : +49 [0]7433 9933
Fax: +49-[0]7433 9933- -149
Internet: www.sauter.eu
Instruction Manual
Digital Force Gauge
SAUTER FH-S
V. 9 1.
05 201/ 8
GB
FH-S-BA-e-1 819
PROFESSIONAL MEASURING

2 -S- -e- FH BA 1819
GB
SAUTER FH-S
V. 05 18 1.9 /20
Instruction Manual Digital Force Gauge
Thank you for buying a SAUTER force gauge with an internal load cell. We hope you
are pleased with your high quality measuring instrument with its big functional range.
If you have any queries, wishes or helpful suggestions, do not hesitate to call our
service number.
Summarize:
1 Introduction.................................................................................................... 3
2 Scope of delivery ........................................................................................... 3
3 Working conditions ....................................................................................... 4
4 4 Specifications ................................................................................................
5 Electrical Power Supply ................................................................................ 4
6 Operation........................................................................................................ 4
6.1 Operation keys .......................................................................................................................... 5
7 Configuration of RS 232 interface ................................................................ 8
7.1 Output Protocol ........................................................................................................................ 9
8 9 Warnings ........................................................................................................
9 Adjustment Procedure FH ........................................................................... 12

FH-S- -e- 3 BA 1819
1 Introduction
Annotation: Please read the in this instruction manual carefully before the remarks
first use, even if you are already experienced with our SAUTER measuring devices.
After receipt of your force gauge, please check the instrument whether any transport
damages have occurred. Please check, whether the outer packaging, the plastic
housing or any other parts or even the instrument itself have been damaged. If any
damages are determined, please inform SAUTER immediately.
SAUTER offers oftware a ssuitable and a wide range of accessories optionally. So
you are able to configure your measuring instrument more versatile. Please ask us at
SAUTER or your SAUTER reseller or just visit us our website on www.sauter.eu
2 Scope of delivery
- SAUTER FH-S, incl. rechargeable battery
- Carrying Case
- Charger
- Standard Attachments as shown aside
Delivered with all -FH S instruments up to 500N
5 pieces M3 x 8 screws for fixation on all SAUTER Test Stands
.
Power plug of
battery charger
Reset button
- LCD Display
Pilot lamp for
Limit value
indication
RS 232
Force sensor
M6 thread
Operation
keys
R
Dimensions in mm
Reset key
Adaptor
socket
4x M3 fixing
screws
