Page 1/14
FC- -e- BA 2020
Sauter GmbH
Ziegelei 1
D-72336 Balingen
e-mail: info@kern-sohn.com
Phone : +49- [0]7433- 9933-0
Fax: +49- [0]7433-9933- 149
Internet: www.sauter.eu
Instruction manual digital force
gauge
SAUTER FC
Version 2.0
01/2020
GB
PROFESSIONAL MEASURING
2 - -e- FC BA 2020
GB
SAUTER FC
V. 2.0 04/2020
Instruction manual digital force gauge
Congratulations on the purchase of a digital force measuring device with internal
measuring cell from SAUTER. We hope you will enjoy your quality measuring device
with a wide range of functions. Please do not hesitate to contact us if you have any
questions, requests or suggestions.
Table of contents:
1 Introduction .................................................................................................... 3
2 Scope of delivery ........................................................................................... 3
3 Technical data ................................................................................................ 4
3.1 Technical data FC with internal loadcell up to 1kN 4..............................................................
4 Display indication .......................................................................................... 5
5 Control buttons .............................................................................................. 6
6 Menu items ..................................................................................................... 7
6.1 Language ................................................................................................................................... 7
6.2 Display modes .......................................................................................................................... 7
6.3 Storing measured values ......................................................................................................... 7
6.4 Delete all records ...................................................................................................................... 7
6.5 Browse Menu ............................................................................................................................ 8
6.6 System settings ........................................................................................................................ 8
6.7 USB/Loading ............................................................................................................................. 9
6.8 Multifunctional port .................................................................................................................. 9
6.9 RS-232 specication: ............................................................................................................... 9
7 Warnings ...................................................................................................... 10
8 Adjustment FC ............................................................................................. 13
9 Technical drawings ...................................................................................... 14
FC- -e- 3 BA 2020
1 Introduction
Please read these operating instructions carefully before commissioning, even if you
already have experience with SAUTER measuring instruments.
After receipt of the force gauge, it should be checked in advance that no transport
damage has occurred, that the outer packaging, the plastic housing, other parts or
even the gauge itself have not been damaged. If any damage is evident, please
notify SAUTER GmbH immediately.
The FC can measure tensile and compressive forces very accurately and it is easy to
operate. It can be held in the hand for measurements or mounted on a suitable test
stand.
SAUTER oers optional software and accessories to make the measuring instrument
more versatile in use. Please ask SAUTER or the SAUTER supplier or visit our
website
www.sauter.eu.
2 Scope of delivery
• SAUTER , incl. internal battery FC
• Transport case
• Battery charger
• 5 pieces M3 x 8 screws for mounting on SAUTER test benches
• Standard attachments standard , as shown M6
extension bar: 90mm
