INOGENI TOGGLE
ROOMS
User guide
Version 0.1
January 18, 2024
– Toggle Rooms User Guide – Version 0.1 1
VERSION HISTORY
CONTENTS
Version history ............................................................................................................................................................................. 1
Typical applications ...................................................................................................................................................................... 2
Room PC mode with BYOD content sharing ........................................................................................................................... 2
BYOM mode ............................................................................................................................................................................. 2
Block diagram .............................................................................................................................................................................. 3
Connectivity diagram ................................................................................................................................................................... 4
Device interfaces ......................................................................................................................................................................... 5
LEDs behavior ............................................................................................................................................................................. 6
Operating modes ......................................................................................................................................................................... 6
Automatic.................................................................................................................................................................................. 6
Manual ...................................................................................................................................................................................... 6
Manual with fallback ................................................................................................................................................................. 6
Specifications ............................................................................................................................................................................... 7
Serial communication protocol ..................................................................................................................................................... 9
REST API ................................................................................................................................................................................... 14
Telnet ......................................................................................................................................................................................... 19
INOGENI Maestro application.................................................................................................................................................... 20
Mechanical specifications .......................................................................................................................................................... 21
DIP switches .............................................................................................................................................................................. 23
Troubleshooting section ............................................................................................................................................................. 23
Support ....................................................................................................................................................................................... 24
Certifications .............................................................................................................................................................................. 24
Version Date Description
0.1 January 17, 2024 Preliminary user guide for device launch.
– Toggle Rooms User Guide – Version 0.1 2
TYPICAL APPLICATIONS
Here is a typical connection diagram used for the TOGGLE ROOMS device in a videoconferencing setup.
ROOM PC MODE WITH BYOD CONTENT SHARING
In this mode, only the Room PC USB and HDMI connections are routed to
the main USB and HDMI peripherals.
The Room PC is the system that is currently selected to the main USB and
HDMI peripherals. However, if the user would like to send HDMI content
from the laptop’s USB-C or HDMI connection to the Room PC, it is
possible to do so with the HDMI SHARE output connection.
BYOM MODE
In this mode, the laptop is the system that is currently selected to the main
USB and HDMI peripherals. The Room PC is completely disconnected
from the setup.
