Indiana Line Basso 950 Manual
Indiana Line
Subwoofer
Basso 950
Read below 📖 the manual in Italian for Indiana Line Basso 950 (12 pages) in the Subwoofer category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/12
B A S S O
8 3 0 & 8 5 0
9 3 0 & 9 5 0
s u b w o o f e r a t t i v i
a c t i v e s u b w o o f e r s
manuale d’istruzioni
o w n e r ’ s m a n u a l
2
subwoofer attivo
•
active subwoofer
Basso 830 Basso 850
diametro altoparlante •
speaker diameter
220 mm 275 mm
tipo di carico •
enclosure load
twin reflex port twin reflex port
tipo di amplificatore •
amplifier type
AB-Class AB-Class
potenza nominale •
nominal power
75 W 150 W
potenza massima
•
max power
125 W 200 W
risposta in frequenza •
frequency response
36
÷
180 Hz 27
÷
180 Hz
frequenza di crossover •
crossover frequency
40
÷
180 Hz 40
÷
180 Hz
alimentazione •
power supply
220
÷
240 V 220
÷
240 V
consumo massimo •
max power consumption
125 W 250 W
stand-by •
stand-by consumption
0.8 W 0.8 W
fusibile •
fuse
1.0 A 2.0 A
dimensioni •
dimensions
250 x 305 x 420 mm 310 x 335 x 440 mm
peso •
weight
8.8 Kg 12.2 Kg
schermo magnetico
magnetic shield
non schermato
no shielded unit
non schermato
no shielded unit
finitura
finishes
vinile nero opaco
mat black vinyl
vinile nero opaco
mat black vinyl
DOPPIO CONDOTTO REFLEX
TWIN REFLEX PORT
3
subwoofer attivo
•
active subwoofer
Basso 930 Basso 950
diametro altoparlante •
speaker diameter
220 mm 275 mm
radiatore passivo •
passive radiator
220 mm 275 mm
tipo di amplificatore •
amplifier type
D-Class D-Class
potenza nominale •
nominal power
250 W 300 W
potenza massima
•
max power
400 W 500 W
risposta in frequenza •
frequency response
25
÷
180 Hz 24
÷
180 Hz
frequenza di crossover •
crossover frequency
40
÷
180 Hz 40
÷
180 Hz
alimentazione •
power supply
220
÷
240 V 220
÷
240 V
consumo massimo •
max power consumption
300 W 350 W
stand-by •
stand-by consumption
0.8 W 0.8 W
fusibile •
fuse
3.15 A 3.15 A
dimensioni •
dimensions
270 x 295 x 395 mm 310 x 335 x 435 mm
peso •
weight
12.7 Kg 17.4 Kg
schermo magnetico
magnetic shield
non schermato
no shielded unit
non schermato
no shielded unit
finitura
finishes
vernice nera opaca
mat black paint
vernice nera opaca
mat black paint
RADIATORE PASSIV O
PASSIVE RADIATOR
