Impact Venture TTL-600 Manual
Read below 📖 the manual in Italian for Impact Venture TTL-600 (32 pages) in the Lamp category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/32
INSTRUCTIONS
VE-TTL
Venture TTL 600 Ws
Monolight Kit
2
Thank you for choosing Impact.
The Venture TTL-600 is a professional monolight that’s powered by a
powerful lithium-ion battery. It features two selectable ash modes
that offer maximum exibility in a variety of shooting applications.
Quick mode provides shorter ash durations and recycle times.
Power mode delivers greater power output for optimal aperture and
shutter camera settings.
This 600 Ws TTL monolight integrates advanced IGBT technology
that enables ultrafast switching and makes fast ash durations at
higher output powers possible. Digital color correction circuitry
stabilizes the color temperature throughout the power range of both
modes within a variance of 50 K.
The monolight has group and channel functions as well as
selectable personal ID numbers. These features allow you to
isolate your units and prevent them from being triggered by other
ashes in the vicinity. For TTL and HSS operation, the monolight has
integrated 2.4 GHz receivers for Canon, Nikon, and Sony when used
with the Venture Wireless Controller. In studio applications, the
Venture TTL 600 has an optical sensor for optical slave use.
Small, lightweight, and easily transported, the Venture monolight
is powered by a lithium-ion battery that provides up to 500 ashes
at full power. A bright and adjustable 1500 lm modeling LED draws
minimal power and can be adjusted independently or proportionally
with the ash power output. With the included universal battery
charger, you can use the Venture TTL 600 at home or abroad.
Introduction
3
• 600 Ws monolight
• Two ash modes: Quick and
Power
• Supports TTL and HSS
when used with the Venture
TTL Wireless Controller
• Wireless TTL, optical slave,
and direct sync options
• Flash duration from 1/455 to
1/19,500 sec.
• Adjustable 1500 lm LED
modeling lamp with four-
option menu
• Modeling light functions as
visual recycle indicator in
certain modes
• Built-in 2.4 GHz receivers
for Nikon, Canon, and Sony
• User-replaceable ashtube
• Thermal switch protects
circuitry from overheating
• Advanced IGBT circuitry
enables fast switching at
high power
• Digital Color Correction
Circuit for stabilizing color
temperature throughout
the power ranges of both
operating modes
Box Contents
• Venture TTL Monolight
• Battery
• Battery charger
• Stand mount
• Pistol grip
• Grid reector
• PC cord
• Aluminum case with
shoulder strap
• User manual
Features
Product Specifications
| Brand: | Impact |
| Category: | Lamp |
| Model: | Venture TTL-600 |
