LS-CS40MK / CS40MBK
C-Stand with Sliding Leg 40 in. Kit
Silver model shown
Thank you for choosing Impact.
The Impact C-Stand with Sliding Leg 40 in. Kit comprises a sliding leg
C-stand, grip head, and extension arm. The C-stand features a top leg
that slides up and down the main riser so you can set up your C-stand on
uneven ground—like stairs or a steep incline—or on furniture, sidewalk
curbs, or set pieces. The other two legs feature a locking mechanism
that allows them to swing out and lock into place for easy setup, and to
collapse flat so you can store your C-stands side by side.
With the included grip head and extension arm, you can use the Impact
C-Stand Kit to hold lights and light modifiers, such as flags, “cookies,”
etc. This kit is ideal for mounting heavy items because the stand has a
low center of gravity, and it easily accepts saddlebag-style sand bags for
additional stability.
The Impact C-Stand with Sliding Leg 40 in. Kit is compatible with other grip
equipment available from Impact Studio Lighting. For more information,
refer to the chapter of this pamphlet.Recommended Accessories
Specifications
Minimum height – 4.5 ft. (1.37 m)
Maximum height – 10.99 ft. (3.35 m)
Closed length – 53.94 in. (137 cm)
Footprint diameter – 39.37 in. (1 m)
Kit weight – 23 lb. (10.43 kg)
Maximum load capacity – 22 lb. (9.98 kg) as a stand
Attachment size – 5/8 in. male stud
Grip arm length – 40 in. (101.6 cm)
Grip head size – 2.5 in. (6.35 cm)
• Do not attempt to disassemble or repair the equipment—doing so will
void the warranty, and Impact Studio Lighting will not be responsible for
any damage.
• Handle the unit with care.
• Clean the unit with a soft dry cloth.
• Keep this unit away from children.
• Use only parts provided by the manufacturer.
• Make sure everything is secure before proceeding.
• Make sure the item is intact and that there are no missing parts.
• Do not exceed the maximum load capacity.
• All photos are for illustrative purposes only.
• Impact CT40M Turtle Base C-Stand, Silver
• Impact KCP-200 2.5 in. Grip Head, Silver
• Impact KCP-240 40 in. Extension Arm, Silver
• Impact CT40MB Turtle Base C-Stand, Black
• Impact KCP-200B 2.5 in. Grip Head, Black
• Impact KCP-240B 40 in. Extension Arm, Black
• Impact CC-106T Super Clamp with T-Handle
• Impact LS-3S Two Section Backlight Stand
• Impact R1142 5-in-1 Collapsible Circular Reflector Disc
• Impact SBF-B-5 (5 lb.), SBF-B-15 (15 lb.), SBF-B-25 (25 lb.), and
SBF-B-35 (35 lb.) Saddle Sandbags, available in Black or Orange
Visit our website at www.impactstudiolighting.com for more Impact
accessories.
