Imarflex Smokeless Griller GL-2700GSF Manual
Imarflex
Grill plate
Smokeless Griller GL-2700GSF
Read below 📖 the manual in Italian for Imarflex Smokeless Griller GL-2700GSF (5 pages) in the Grill plate category. This guide has been helpful for 4 people and has been rated 4.5 stars on average by 2 users
Page 1/5
SPECIFICATION:
MODEL NO. : -27 GSF GL 00
RATED VOLTAGE : 230Va.c. 60Hz
POWER CONSUMPTION : 00 Watts 15
BOX DIMENSION : 545*210*330mm
UNIT DIMENSION : 500*303*203mm
GROSS WEIGHT : 7.19kg.
UNIT WEIGHT : 6.63kg.
IMPORTANT SAFEGUARD:
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions carefully.
2. Do not use the appliance on any metal table.
3. Do not use the appliance next to devices which react sensitively to magnets (e.g.
radios, TV, cassette recorders, etc.).
4. Keep curtains, furniture, ammable materials, etc. away from the appliance and from
the convenience outlet where the appliance is plugged.
5. Before using the appliance, check if the voltage indicated corresponds with the
convenience outlet (230Va.c.)
6. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should
be replaced with the same type and size or bring the appliance to the nearest
Authorized Service Center.
7. Do not use a two-way socket with another appliance.
8. Do not place the unit near a gas stove, an electric burner, in a heated oven or near any
hot surface.
9. Do not touch the appliance and the power plug with wet hands.
10. Do not allow the cord to touch the hot surface of the unit.
11. Do not place any metal kitchen utensils, knives or other metal objects on the appliance.
These may heat up when the appliance is turned on.
12. Do not place any magnetic objects on the grill plate while the appliance is in use.
13. To protect against electric shock, do not immerse the unit and the thermostat control in
water or any other liquids.
14. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliances by
the person responsible for the safety. Children should be supervised to ensure that
they do not play with the appliance.
15. Extreme caution must be taken in moving an appliance containing hot oil or liquids.
16. Make sure that the unit is unplugged before replacing or removing any of its parts or
accessories.
17. Do not touch the appliance while cooking is in progress.
18. Do not use the appliance for other than its intended use.
19. Use of accessories or equipment not supplied by the manufacturer may cause damage
or malfunctioning of your appliance or result in injuries.
20. CAUTION: Never leave the unit unattended while cooking.
21. The appliance is not intended for outdoor use.
22. For household use only, not intended for any business purposes.
23. Save this instruction for future references.
24. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cutout,
this appliance must not be supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on and o by the utility.
DESCRIPTION OF PARTS: CONTROL PANEL:
HOW T ASSEMBLE: O
1. For rst time use, remove all packaging materials before use.
2. Place the unit on a at stable surface.
3. Make sure that the built-in fan is properly placed in the unit body.
4. Place the o / water tray inside the unit body properly ( should be steady) and pour 2 cups il it
of water.
5. Place the drip tray above the oil / water tray followed the heating element. by
*Note:
- Arrows in the drip tray should be facing right.
- Failure to place the heating element properly, the unit will not work.
6. Choose the desired attachment (griller or skillet) and put it on the top of the heating element.
7. Assemble the Glass lid cover properly. Refer to the photo below
Product Specifications
| Brand: | Imarflex |
| Category: | Grill plate |
| Model: | Smokeless Griller GL-2700GSF |
