Page 1/24
User Guide English (3–6)
Guía del usuario Español (7–10)
Guide d’utilisation Français (11–14)
Guida per l’uso Italiano (15–18)
Benutzerhandbuch Deutsch (19–22)
Appendix English (23)
Expression Pedal
2
3
1/4" (6.35 mm)
TS - Toe Switch
1/4" (6.35 mm)
TRS - Expression Pedal
User Guide ( )English
Box Contents
HeadRush Expression Pedal
6 mm Hex Key
User Guide
Safety & Warranty Manual
Support
For the latest information about this product (documentation, technical specifications, system
requirements, compatibility information, etc.) and product registration, visit headrushfx.com.
For additional product support, visit headrushfx.com/support.
Features
1. Foot Pedal: Place your foot on the foot pedal and move the
pedal from the toe-down to toe-up position (and vice-versa)
to adjust the parameter(s) on your connected device.
2. Toe Switch: Push down on the toe portion of the pedal
when it is in the toe-down position to activate the toe switch
function.
3. Tension Adjustment Screw: This screw enables you to
adjust the action” of the pedal to suit your style by using
the included 6 mm hex key. If you would like a tighter or
heavier movement of the pedal, turn the screw clockwise. If
you would like a smoother or softer pedal movement, turn
the screw counter-clockwise.
Important: For fine adjustment only. Do not turn the bolt more than a 1/2 revolution in either
direction.
4. Expression Pedal Output: (1/4”/6.35 mm, TRS): Connect this output to the expression pedal
input of your device using a standard 1/4" (6.35 mm) TRS cable. See the diagram below for an
example of a TRS connector.
5. Toe Switch Output: (1/4”/6.35 mm, TS): Connect this output to the toe switch input of your
device using a standard 1/4" (6.35 mm) TS cable. See the diagram below for an example of a
TS connector.
1
3
4
5
2
