Page 1/4
Owner’s Manual
Havis Rugged USB
Backlit Keyboard
KB-101_OMN_4-16
www.havis.com
1-800-524-9900
DS-GTC-301
DS-GTC-301-3
DS-GTC-302
DS-GTC-302-3
DS-GTC-303
DS-GTC-305
KB-101
Havis, Inc.
75 Jacksonville Road
Warminster, PA 18974
www.havis.com 1-800-524-9900
2 7
• NEVER STOW OR MOUNT THE RUGGED KEYBOARD DIRECTLY IN A
VEHICLE AIRBAG DEPLOYMENT ZONE.
• DO NOT USE RUGGED KEYBOARD WHILE DRIVING.
• RECOMMENDED TO SET THE CONNECTED COMPUTER’S POWER OPTIONS
TO “NEVER” SLEEP.
• RECOMMENDED TO SET THE CONNECTED COMPUTER’S BIOS TO “ENABLE USB
WAKE SUPPORT”.
- Push ‘F2’ key during the computer’s boot sequence
- Select SETTINGS
- Select POWER MANAGEMENT
- Select USB WAKE SUPPORT
- Check the box for ENABLE USB WAKE SUPPORT
- Left Click: APPLY
- Left Click: EXIT
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
KB-101
Before Beginning
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the KB-101 Rugged USB Backlit Keyboard.
For questions regarding the set-up of your KB-101 RUGGED USB Keyboard, please
contact Havis at 1-800-524-9900 or visit www.havis.com for additional product
support and information.
This Owner’s Manual applies to the following Part Numbers:
Related Products
Havis offers a wide variety of accessory products specically for use
with the KB-101 Rugged USB Keyboard. For more information or to
order, please visit www.havis.com.
C-KBM-201
Keyboard Mount
Quickly dock and undock your Havis Rugged Keyboard with
this equally rugged mount. No tools or hardware required.
6 3
Specications
Working Voltage Standard USB (+5V DC ± 10%)
Dimensions 5.8” ( 14.8 cm) H x 11.3” ( 28.6 cm ) W x 0.4” ( 1.1 cm ) D
Weight 2.0 lbs ( 0.91 kg )
Operating Environment -21° C to 60° C ( -6° F to 140°F ) - 100% Humidity
Storage Environment -40° C to 85° C ( -40° F to 185° F ) - 100% Humidity
• Do not place metal objects on top of the Rugged Keyboard
• Do not leave the Rugged Keyboard in a high temperature environment (greater than 85°C, 185°F)
for a long period of time
Precautions
Backlight:
• Backlight ON/OFF Button:
Switches keyboard illumination
between On and Off
• ‘Fn’ + (‘F11’ or ‘F12’):
Adjusts the backlight intesity
Volume:
• ‘Fn’ + ‘F8’:
Mute sound
• ‘Fn’ + (‘F9’ or ‘F10’):
Adjusts the volume level
Emergency:
• ‘Emergency’ Button:
Sends a ‘SHIFT’ + ‘F1’ key sequence
to the connected computer
Multi-Touch Mouse Pad:
• More than one nger can be used at a time
- Single point: Cursor position control
- Two point: Scroll up/down
Operation
Cleaning
The Havis Rugged Keyboard can be cleaned with a soft cloth and a non-corrosive
cleaning solvent.
• USE A SOFT CLOTH OR SPONGE TO CLEAN.
• DO NOT USE A STIFF BRUSH. NO INTENSE SCRUBBING.
• RESISTANT TO HOSPITAL GRADE ALCOHOLIC CLEANERS.
• DO NOT USE CORROSIVE CLEANING SOLVENTS.
Compatibility
• MAC, Microsoft Windows 7/8/Vista /Xp/2000/ME/98
• COMMUNICATION INTERFACE: USB 1.1 or 2.0
Product Specifications
| Brand: | Havis |
| Category: | Keyboard |
| Model: | KB-101 |
