Page 1/12

Quick Installation Guide

A ALTHE 18W

A A BLTHE 18

Schnellinstallationsanleitung

Guide d'Installation Rapide

Guía de Instalación Rápida

Guida di Installazione Rapida

Gyors Telepítési Útmutató

Szybka Instrukcja Instalacji

Guia de Instalação Rápida

Model

A LTHEA18W (White)

A LTHEA18B (Black)

AC I nput

100.0 ~ 240.0V 50/60Hz, 2 A max .5

DC O utput

USB C 1/2 output: -

5.0V/3.0A, 9.0V/3.0A, 12.0V/3.0A,

15.0V/3.0A, 20.0V/5.0A (PD 100.0W);

3.3 11.0V/4.05A (PPS)-

USB C 3 output: -

5.0V/3.0A, 9.0V/2.22A, 12.0V/1.67A (PD

20.0W); 3.3-11.0V/2.0A (PPS)

USB- A output:

4.5V/5.0A, 5.0V/4.5A, 9.0V/2.0A,

12.0V/1.5A (QC 3.0)

Total Output

1 00.0 Max

Average Efficiency

( ) 230VAC, 50Hz

87.26% for 5.0V/3.0A + PD 1: PD 2:

5.0V/3.0A + PD 3: 5.0V/2.0A + USB-A:

5.0V/2.0A

90.20 20% for PD 1: .0V/2. A + PD 2: 25

20 1.5.0V/ A + PD 3: 5.0V/2.0A + USB-A:

5.0V/2.0A

Efficiency at load 10%

( ) 230VAC, 50Hz

80.51% for PD 1: 5.0V/3.0A + PD 2:

5.0V/3.0A + PD 3: 5.0V/2.0A + USB-A:

5.0V/2.0A

83.17% for PD 1: 20.0V/2.25A + PD 2:

20.0V/1.5A + PD 3: 5.0V/2.0A + USB-A:

5.0V/2.0A

No Load Power Consumption

≤0.3W

Protection

Short Circuit Protection

Over Current Protection

Over Voltage Protection

Operating temperature / humidity

0°C ~ / 20% ~ 80% RH 35°C

Storage temperature / humidity

-20°C ~ 80°C / 10% ~ 90% RH

Dimensions (W x D x H)

65 65 32 x x mm

W eight

204g

Quick

Installation

Guide

PACKAGE CONTENTS

Lieferumfang Contenido del paquete Contenu de l'emballage Csomag tartalma | | |

Contenuto della confezione | Conteúdo da embalagem | Zawartość opakowania

SPECIFICATION

Spezikation Especicaciones Spécications Speciche | | | | Műszaki adatok

Specykacja | Especicações

1-PORT CHARGING

2-PORT CHARGING

MULTI-PORT CHARGING

La tp op T le Phoneab t

PD100W

PD20W

QC18W/

22.5W

PD65W

PD30W

PD65W

PD20W

PD65W

QC18W/

22.5W

2-PORT CHARGING

PD65W

QC18W/

22.5W

5V2A

PD45W

PD30W

PD65W

PD30W

PD20W

QC18W/

22.5W

5V2A

PD45W

PD30W

5V2A

PD65W

5V2A

PD45W

INSTALLATION

Installation Instalación Installation Installazione Telepítés Instalacja | | | | |

Instalação

POWER OUTPUT

Leistungsausgang Salida de energía | | Puissance de sortie Potenza in uscita |

Teljesítmény kimenet Saída de energia | Moc wyjściowa |
