Quick Installation Guide
A ALTHE 1 W0
Schnellinstallationsanleitung
Guide d'Installation Rapide
Guía de Instalación Rápida
Guida di Installazione Rapida
Gyors Telepítési Útmutató
Szybka Instrukcja Instalacji
Guia de Instalação Rápida
INSTALLATION
Installation Instalación Installation Installazione Telepítés Instalacja | | | | |
Instalação
SPECIFICATION
Spezikation Especicaciones Spécications Speciche | | | | Műszaki adatok
Specykacja Especicações|
AC Input
100.0-240.0V, 0.6A max, 50/60Hz
DC Output
PD 3.0 5.0V/3.0A, 9.0V/2.77A, :
12.0V/2.1A
PPS: 3.3-5.9V/3.0A, 3.3-11.0V/2.75A
Total Output
25.0 Max
Average Active Eciency
81.75% for 3.3V/3.0A
85.20% for 5.0V/3.0A
88.68% for 11.0V/2.27A
88.61% for 12.0V/2.1A
Eciency A Load 10% t
75.38% for 3.3V/3.0A
76.80% for 5.0V/3.0A
77.09% for 11.0V/2.27A
79.25% for 12.0V/2.1A
No Load Power Consumption
≤0.1W
Protection
Short Circuit Protection
Over Current Protection
Over Voltage Protection
Operating Temperature / Humidity
0°C ~ °C / 10% ~ 80% RH 40
Storage Temperature / Humidity
-20°C ~ 80°C / 5% ~ 95% RH
Dimensions (W x D x H)
40.2 x 26 x 43.5 mm
Weight
57g
English
Installation & usage
◼ Plug the USB charger into a free wall outlet.
◼ Connect your USB device to the USB charger with the USB charging cable.
Safety a Warnings instructions nd
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on proper
handling in this manual, we assume no liability for any resulting personal injury or
damage to property. Such cases will invalidate the warranty/guarantee.
◼ Keep the device away from water, humidity, re or hot environments.
◼ Keep your device and all its parts and accessories out of the reach of small
children.
◼ Do not leave the packaging material lying around carelessly. This may become
dangerous playing material for children.
◼ Do not use the device if there are any signs of damage to the housing, plug, or
cable.
◼ Avoid dropping, throwing or crushing the device.
◼ Conrm that the wall outlet provides the same type of power indicated on the
device (both Voltage [V] and frequency [Hz]).
◼ Use the power supply only in a socket that is installed as close as possible to the
device and easily accessible and easy to unplug.
◼ Do not plug the power supply in a socket that is hidden behind of any furniture.
◼ Do not cover the power supply connected into the socket.
◼ Use the product only in dry indoor rooms and protect it from moisture.
◼ If in doubt or if the power adapter malfunctions, discontinue use and contact our
customer support or an authorized service centre.
◼ Discontinue use immediately if the power adapter shows visible damage, emits
unusual odours, or becomes excessively hot.
◼ Disconnect the product from the mains before cleaning.
◼ Clean the product with a dry, bre-free cloth.
Disposal of waste electrical equipment: Dispose of the product at a
recycling point. Do not dispose of together with household waste.
Incorrect storage/disposal can harm the environment and/or cause
injury.
CE marking: Conceptronic declares that this product complies with
the directives listed in the section 'Declaration of Conformity'.
Product Specifications
| Brand: | Equip |
| Category: | Charger for mobile device |
| Model: | ALTHEA10W |
