Page 1/4
User's Guide
ELPMB Truss Mount Adapter 71
V12H006AH0
Email: info@euromet.com
EM 09216
Safety Precautions
DANGER
• Failure to comply with these safety precautions results in death or serious injury;
• ELECTRICAL SHOCK HAZARD! Always turn o, disconnect, and disengage all power
sources to the projector before servicing;
• Maximum projector weight limit is 45kg (99 lbs).
WARNING
Failure to comply with these safety precautions may result in serious injury.
• At least two qualied people should perform the installation procedure. Personal injury
and/or property damage can result from dropping or mishandling the projector;
• If mounting to ceiling studs, make sure that the mounting screws are anchored into the
center of the ceiling studs. Use of an edge- -edge stud nder is recommended; to
• Be aware of the mounting environment. If drilling and/or cutting into the mounting surface,
always make sure that there are no electrical wires in the wall;
• Do not install near sources of high heat. Do not install on a structure that is prone to
vibration, movement or chance of impact.
TOOLS INCLUDED
• 5 mm hex key;
General information and compatibility
The adapter for trusses allows you to hook directly the mount to a truss / truss of any size in a
stable and lasting way.
The component is easy to use because it allows the replacement of the plates to be attached
to the ceiling and being universal, it is able to attach any Clamp. This makes the mount perfect
also for rental installations for events and can be used on any truss.
The system conrms the eectiveness of this present system thanks to the xing with an Allen
key.
Max load
45 kg
Tilt angle
Up to 30°
Swivel
360°
Product Specifications
| Brand: | Epson |
| Category: | Beamer |
| Model: | ELPMB71 |
