Page 1/6
ANGEN
IN-VEHICLE ELECTRONICS
INTER FACING SOL UTIONS
by:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.080220
CTR-W7
Commercial Grade Wireless Truck Camera with
7 inch Wide Screen Monitor
1 of 6
WIRELESS CAMERA
- 2.4 GHz, 20 Channel Frequency Hopping Method for clear image.
- 120 eecve viewing angle.
- 8 IR LEDs for up to 10M visibility at night.
- Waterproof camera and transmier (IP 69K).
MONITOR
- 16:9 Wide Screen LCD Monitor with removable sunshade.
- 2 camera inputs.
- Separate trigger control wire with automac switch over for each camera.
- Adjustable parking guide lines generated by monitor.
- Stainless Steel Aviaon connectors.
PRODUCT FEATURES:
PARTS INCLUDED:
Wireless Camera Receiver Transmier
PRODUCT FEATURES:
Use on trucks, SUVs, RVs, Buses and other vehicles that require wireless reverse camera soluon.
7” Monitor Power/Video Harness 4 pin to RCA Adatper (2 pcs) Remote Control
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.080220
CTR-W7
Commercial Grade Wireless Truck Camera with
7 inch Wide Screen Monitor
2 of 6
INSTALLATION INSTRUCTIONS:
1. Find a suitable locaon to install the camera. 2. Test t the bracket to make sure theres is enough
space.
3. Use the screws provided to mount the bracket. 4. Install the camera to the bracket. Do not completely
ghten the screws yet.
5. Above is how the camera should be installed. 6. Mount the transmier no more than 3 feet from the
camera
7. Clean the surface where the transmier will be
mounted.
8. Aach the double sided adhesive to the transmier.
ANGEN
IN-VEHICLE ELECTRONICS
INTER FACING SOL UTIONS
by:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.080220
CTR-W7
Commercial Grade Wireless Truck Camera with
7 inch Wide Screen Monitor
3 of 6
9. Press down on the transmier to adhere to the
surface.
10. Aach the “L” brackets using the screws provided.
11. Use cable es to securely fasten the transmier. 12. We recommend pung silicone sealant around the
base of the transmier to prevent dirt from going behind
the transmier.
13. Disconnect the reverse light connector. 14. Strip the power and ground wires of the reverse light.
15. Tap the red and black wires of the CTR-01Q camera
cable to the posive and negave wires.
16. Reconnect the reverse light connector.
ANGEN
IN-VEHICLE ELECTRONICS
INTER FACING SOL UTIONS
by:
