ANGEN
IN-VEHICLE ELECTRONICS
INT ERFACING S OLUT IONS
by:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.081820
CTM-11YB
Commercial Grade Top Mount Camera
with 1/3” Sony CCD Sensor and IR LEDs
1
• Sensor: 1/3” SONY CCD sensor.
• Pixels: 975H x 582V (NTSC)
• Resoluon: 600TVL (horizonal)
• Viewing Angle: 150°
• Illuminaon - .01Lux (18 IR LEDs)
• Connecon: G16 Aviaon 4pin connectors
• Power Supply: 12V to 24V
• Operang Temperature: -20° - +60°
• Waterproof: IP68 Rated
PRODUCT SPECIFICATIONS:
PARTS INCLUDED:
INSTALLATION DIAGRAM:
CTM-11YB CAMERA 65’ EXTENSION CABLE 4 Pin to RCA Adapter
To Aftermarket Radio
Backup Camera Input
OR
Reverse Camera Interface
Backup Camera Input
65’ Extension Cable
RED - Wire Camera
Power +12V
Black - Ground
Video Input
©
