Page 1/24
ANGEN
IN-VEHICLE ELECTRONICS
INTER FACING SOL UTIONS
by:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021521
CTR-DCM
Commercial Grade Bus/Truck Blind Spot System with
Dual Camera and 12.3” Screen Monitor
1 of 5
CAMERA
- Dual wide view camera with 150o and 90o viewing angles.
- AHD chipset for super clear image quality.
MONITOR
- Split view LCD monitor.
- 2 camera inputs.
- Separate trigger control wire for each camera with full screen view.
- Water resistant aviaon connectors.
- Rated at 24 Volts.
- 64 Gb micro SD card included.
PRODUCT FEATURES:
PARTS INCLUDED:
Dual Lens Wide Angle
Camera
12.3” Split View Monitor Power/Video
Harness
64GB
Micro SD Card
PRODUCT FEATURES:
Use on trucks, buses and other vehicles with 24V systems that require a blind spot eliminaon camera soluon.
Camera Extension Cable
(2 pcs)
Overhead Mount Angle Mount Remote Control
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021521
CTR-DCM
Commercial Grade Bus/Truck Blind Spot System with
Dual Camera and 12.3” Screen Monitor
2 of 5
MOUNTING LOCATIONS:
ANGEN
IN-VEHICLE ELECTRONICS
INTER FACING SOL UTIONS
by:
Inside the bus:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021521
CTR-DCM
Commercial Grade Bus/Truck Blind Spot System with
Dual Camera and 12.3” Screen Monitor
3 of 5
ANGEN
IN-VEHICLE ELECTRONICS
INTER FACING SOL UTIONS
by:
CONNECTION DIAGRAM:
Red = +24V Acc
Yellow = +24V Battery
Black = Ground
Brown = Camera Trigger 1
Green = Camera Trigger 2
INITIAL SETTINGS:
Once the monitor and camera has been installed, it is recommended that the micro SD card be formaed.
Use the remote control provided or the monitor buons to change the sengs.
Press the “OK” buon on the remote control or
the “M” buon on the monitor to enter the main
menu. Use the UP, DOWN, LEFT and RIGHT arrows
to navigate through selecons. Scroll to the “System
Seng” then “Storage Manager”. Select “Storage 1”
and click “Format”.
