R
INTERFACING SOLUTIONS
Sightline
CAMERAS
CSV-FD15
Side Mirror Mounted Camera for Ford F-150
- OEM style camera pods for the le and right side mirrors.
- Includes adjustable angle cameras.
PRODUCT FEATURES:
PARTS INCLUDED:
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
1 of 1 rev.091720
1. Remove the door pull and remove door panel the screws. 2. Remove the door unlock handle cover and remove the screw.
3. Use a plasc pry bar to remove the window sail. Remove the trim
panel clips.
4. Unhook the door panel by pulling it upward. Unplug the speaker
and doorlock harness.
5. Use a hooked pick tool to remove the OEM side mirror cover. Fish
the camera cable through the hole.
6. Tuck in the camera cable inside the cavity and snap in the
CSV-FD15 side mirror cover with camera.
INSTALLATION PROCEDURE:
VEHICLE APPLICATIONS:
FORD
2016 – 2018 F150 (with removable OEM side mirror camera cover at the boom)
Not compable with telescopic type side mirrors.
Product Specifications
| Brand: | CRUX |
| Category: | Security camera |
| Model: | CSV-FD15 |
