Page 1/1
- Specially designed for the Ford Superduty trucks to replace the tailgate handle for an OEM look.
- 160 degree wide view angle for excellent visibility.
- Super CMOS (PC2099) technology provides a sharper image day and night.
PRODUCT FEATURES:
PARTS INCLUDED:
CFD-03E CAMERA BASE EXTENSION CABLE
PARKING LINES: Cut WHITE wire to turn OFF
PAL SYSTEM: Cut BLUE wire
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.041119
CFD-25H
FORD Superduty Tailgate Handle Camera
R
INTERFACING SOLUTIONS
Sightline
CAMERAS
24 Ft. Coax Cable
To Aftermarket Radio
Backup Camera Input
OR
Reverse Camera Interface
Backup Camera Input
+12V (Red)
Ground (Black)
To Reverse Light Wiring
Cut WHITE wire = Parking Line OFF
Cut BLUE wire = PAL System
WIRING DIAGRAM:
1
VEHICLE APPLICATIONS:
FORD
2017 - Up F-250, 350, 450 Superduty
Product Specifications
| Brand: | CRUX |
| Category: | Security camera |
| Model: | CFD-25H |
