Air Compressor
Art.-No.: 40.072.75
C-8/24
bar code: 4006825506204
Sales unit: 1 pc
Mobile, oil-creamed 1-cylinder compressor with directly coupled motor with built-in starter relief.
Especially suitable for spraying, inating of rafts, rubber floats and balls.
1
2
Features:
- Pressure reducer (1)
- air-intake lter
- pressure switch (2)
- 1 gauge for regulating the working -
pressure,
- 1 self-stopping quick coupling
drain valve
back pressure valve
safety valve
under carriage with guide bar
mains cable with earthed plug
CE-vessel certicate to norm EN 286
Technical data:
-
Air intake capacity: 210 l/min.
-
Vessel size: 24 l
-
Speed: 2850 rpm
-
Mains: 230 V~ 50 Hz
-
Motor Power: 1,5 KW / 2 HP (PS)
-
Operating pressure max.: 8 bar
-
Weight: 33,2 kg
-
Packing dimensions: 600 x 285 x 635 mm
