Page 1
OWNER’S MANUAL
© 2003 Audio LtdCEDAR
Manual version 1.02: February 2003
ADA converter
Page 2 Page 3
Table of Contents
Safety Instructions ...................................................................................... 5
Introduction ................................................................................................. 6
Input and Output .................................................................................... 7
Front Panel LED ...................................................................................... 7
Block Diagram ........................................................................................ 7
Rear Panel Connections and Operation ..................................................... 8
Inputs ...................................................................................................... 8
Outputs ................................................................................................... 9
Rear Panel Controls .............................................................................. 10
CE Declaration of Conformity.................................................................... 12
Specications ........................................................................................... 13
Licence and Limited Warranty .................................................................. 14
Page 4 Page 5
SAFETY INSTRUCTIONS
Failure to adhere to the safety instructions may cause severe
damage to the ADA and risk of electric shock.
â– Unpacking
Unpack the ADA carefully. Save the packing materials since you may
need them to transport the unit in the future. In addition to this manual, the
ADA and its packaging, the box should contain a mains lead, rubber feet,
rackmounting accessories and a warranty registration card.
â– Water and moisture
The ADA must not be exposed to rain or moisture. If the ADA is brought
directly from a cold environment into a warm one, moisture may condense
inside it. Always allow the ADA to reach ambient temperatures naturally
before connecting the mains power.
â– Installation site
To maintain reliability and prolong operating life, observe the following
environmental considerations:
â– the temperature should be maintained between 5 and 30 Celsius
â– relative humidity should be in the range 30% to 80% non-condensing
â– strong magnetic fields should not exist nearby.
Do not subject the ADA to strong sunlight, excessive dust, mechanical
vibration or periodic shocks. The unit is not susceptible to excessive heat
build-up, but should be installed away from heat sources such as
radiators and audio devices that produce large amounts of heat.
â– Mains voltage and Earthing (Grounding)
Before connecting to mains power, ensure that (i) the voltage selector is
set to the correct voltage for the local mains supply, and that (ii) the fuse
is of the correct rating, as indicated on the rear panel of the ADA. The unit
must be earthed to ensure a safe operating environment and to provide
electromagnetic shielding.
â– Connections
Turn o the power to all equipment before making any connections.
â– Cleaning
Clean the ADA only with a dry cloth. Never use abrasive pads or liquid
cleaners such as alcohol or benzene.
â– Damage requiring service
The ADA contains no user-serviceable parts and should not be opened by
unauthorised personnel. It should be returned to qualied service agents
when it has been exposed to liquids, when it fails to function correctly,
when it has been dropped, or when the case is damaged.
