Page 1/12
[ 1 ]
Bitspower Nebula VGA Water Block for ASUS ROG Strix and
TUF Gaming GeForce RTX 4090 series (incl. Improved backplate ) V1
1
GPU
(Not included)
Step 1 Step 2
Step 4Step 3
Accessories
1
2
3Back plate
M2.5 x 8 Screw1
BP-VG4090AST-V2 1 SET
1 PC
9 PCS
1 Two screws fastened in advance.
2
2
3
3
Before installing the graphics
card, please make sure that
the GPU has been coated with
thermal paste. In addition, please
tear off the films on the thermal
pads of the water block.
[ 2 ]
Step 5
motherboard
DRGB Multi Function Controller
(Not included)
BPTA-DRGBMFC
1
2
In Out
Digital RGB PIN on 1motherboard or 2
other equipment.
Accessories
1
2
3Back plate
M2.5 x 8 Screw1
BP-VG4090AST-V2 1 SET
1 PC
9 PCS
1
Two screws fastened in advance.
Original I/O(Not included)
Original screw(Not included)
Original bracket(Not included)
[ 3 ]
Make sure the correct thermal pads are in the appropriate locations.
Use an appropriate amount of thermal paste.(Not Include)
1.0 mm Thermal pad 1.5 mm Thermal pad
Name Specification Quantity
2Thermal pad 7 93.8×19.5×1.5mm
4Thermal pad 6 12×52×1mm
8Thermal pad 5 8×12×1mm
1Thermal pad 4 13×16×1mm
2Thermal pad 3 14×50×1mm
4Thermal pad 2 6×52×1mm
1Thermal pad 1 15×37×1mm
3
1
2
3
4
5
6
2
2
2
6
66
5
5
5
5
5
5
5
