Page 1/5
Installation Instructions
Plac ze the Ba ook on tha UTube e ATV rack. If being mounted to a at surface use the mounting bases. Remove bases from strap if being
used on a bar rack or if you do not want to mount strap bases. Wrap strap around the UTube then adjust strap to correct length. Fasten
the buckle lus as Il strated. The strap should o rlo p th ough th kle be buc and e tightened usec rely by holdi e ang th str p in pl ce with a one hand and
pulling the olo se end awa rom y f the buckle, but a inst cga the abinet. Then secure the hook & loop ends to the strap. Repeat with the 3
remaining straps.
UT6200 / UT6200RL
UT8200 / UT8200RL
Strap Placement
Strap Placement
Path of strap
With mounting base
Remove fuse from 6 ft power cable. Attach the red wire to the positive battery terminal. Attach the black wire to the
negative battery terminal. Run power cable to the location of the UTube. making sure power wire does not hinder
the safe operation of the vehicle. Plug the red power cable end into the UTube’s red input power plug. The black 12vdc
accesory plug can be used to power any 12vdc accessory up to 15 amps. Use the black accessory pigtail to wire your
accesories.
Button 1 Press to go back one track, Press and hold to decrease volume.
Button 2 Press to play/pause, Press to answer/hang up phone, Double
press for last number radial or open Siri on Iphone, Press and
hold to unpair bluetooth device.
Button 3 Press to go forward one track, Press and hold to increase volume.
Button 4 Press to power on, press while power is on to switch input between
aux. and bluetooth inputs, Press and hold to power off.
Button 5 Auxiliary 12vdc output on/off switch.
AUX Socket Used for a 1/8” audio cable
Installation Instructions
LED light status indicator:
LED Light Description
Blinking: Bluetooth module is pairing
Solid blue: Bluetooth module is paired
Blue/Red: Bluetooth module is in AUX input mode
Bluetooth module audio indicators:
Audio Response Description
Power on: Module is turned on
Power off: Module is turned off
Beep: After LED light stops blinking means module is paired
Beep: When play/pause button is pressed and held means
module is unpaired from Bluetooth device.
Double Beep: When forward button is pressed and held means
module has reached maximum volume.
LED Light
Input
Microphone
UT6200 / UT6200RL
UT8200 / UT8200RL
Switch 1 On/Off
Remote switch buttons 2-4 are not used with the UT6200RL or the UT8200RL models
Installation Instructions
UT6200RL
UT8200RL
RF fuctions and the RF remote are only available
the UT6200RL and UT8200RL models
Switch aux. 12vdc (15 amp) ouput.
off
Product Specifications
| Brand: | Bazooka |
| Category: | Speaker |
| Model: | UT8200 |
