BASSBOSS BB15-MK3 Manual
Read below š the manual in Italian for BASSBOSS BB15-MK3 (16 pages) in the Speaker category. This guide has been helpful for 7 people and has been rated 4.5 stars on average by 2 users
Page 1/16
User ManUal
Single 15ā
Powered Subwoofer
BB15-MK3
BB15-MK3 User Manual
2
Table of Contents
Overviewī 2
QuickīStartīGuideī 4
OutboardīProcessorīWarningī 5
SetupīProcedureī 5
OperationīandīControlsī 6
IndicatorīLEDsī 6
HowītoīUseītheīPresetsī 7
Pre-InstalledīOnboardīPresetsī 8
PowerīDistributionī 9
Troubleshootingī 9
CardioidīModeī 10
Specificationsī 11
Warrantyī 12
SafetyīInformationī 13
ImportantīNotesī 14
FCCīComplianceīNoticeī 14
Overview
BASSBOSS continues to push the envelope of design for mobile-optimized subwoofers.
The BB15-MK3 subwooferās compact size and excellent output-to-price ratio was designed for gigging
DJs, home studio bass-heads, or venue owners with limited space.
A powerful, easily portable system that delivers superior sound quality, the BB15-MK3 oīers remarkably
deep bass for its size. Plug-and-Play ease of use is facilitated by an integrated DSP while a 2500 watt
amplifier and a 4.5ā coil Neo woofer make the compact, lightweight design extremely eīective. Although
only 21ā x 17ā x 24ā and 71lbs, its output SPL and low-frequency extension capabilities exceed many
much bigger boxes.
For DJs and venues seeking high levels in tight spaces, the BB15-MK3 is the smallest, lightest and most
EsteīmanualīestĆ”īdisponibleīenīespaƱolīenīnuestroīsitioīwebīenībassboss.com/support
Single 15ā
Powered Subwoofer
BB15-MK3
bassboss.com
3
eīective solution available. Perfectly capable of providing high SPL starting from 40Hz, thereās barely
any event this little box canāt do. When you want the biggest output from the smallest sub, the BB15-MK3
is what you want.
The BB15-MK3 is a single 15-inch direct-radiating subwoofer. Featuring a long excursion, 15-inch woofer
loaded into a vented enclosure that is tuned to optimize low frequency output using a large port. The
amplifier is loaded at the interior port end to utilize the air flow at high output for additional cooling.
The BB15-MK3 features a 2500W amplifier with an auto-sensing, globally compatible power supply
that can run on mains supplies anywhere between 90 and 250 Volts. Full output power is available on
anything over 110V. The amplifierās high peak-output voltage provides for intense high SPL hits while its
sustained output is unparalleled in its ability to deliver the liquid lows. The amplifier is passively cooled
via its external heat-sink and by woofer-generated air-flow through the port. When necessary, two
blower-fans will engage to provide additional forced-air cooling capacity in more extreme conditions.
New to the MK3 are Neutrik powerCON True 1 TOP (Total Outdoor Protection) waterproof mains
connectors. Waterproof mains connectors, along with a totally isolated input connection section and
cones that are waterproofed, make the MK3 series the powered loudspeakers that can be used outdoors
without fear of what the weather will bring, or used indoors without fear of what the partiers bring.
Electrical power is converted into the much more desirable acoustical power by a robust, neodymium
motor, 15-inch woofer with a massive 4.5 inch (115mm) copper-wound voice coil. Neodymium magnets are
lighter, and their higher intensity provides higher eīiciency, so the result is a lighter and louder cabinet
than those with ferrite drivers.
The MK3 features an all-new DSP. The comprehensive suite of processing includes high-pass and low-
pass filters as well as multiple protection systems and limiters to prevent driver overload in as many
ways as possible, including thermal, excursion and clipping. The five levels of protection actively prevent
overheating of the voice coil, minimize long-term thermal compression and limit excursion. Because they
operate in 5 diīerent modes, the limiters are sophisticated enough to have a largely unnoticable eīect
on the transient response and allow the subwoofer to deliver peak output safely.
The new DSP features an Ethernet interface. This can be used to control the cabinets from a computer
or to load software or firmware updates. The ethernet connectivity in conjunction with the DSP board
allows signal to be sent via Milan AVB. Firmware updates will provide access to this feature.
Within the software, multiple cabinets can be grouped together, allowing them to respond to commands
simultaneously. This permits the levels of multiple loudspeakers to be adjusted together and yet
independently from the levels of other groups of loudspeakers. In addition to individual and grouped
level controls, presets can be loaded and signal levels and temperatures can be monitored. Each cabinet
includes a two-port switch so multiple cabinets can be chained on the same data cable.
The MK3 DSP features storage capacity of up to 100 presets, eight of which can be accessed at the touch
of a button with no need for a connected computer. The eight directly accessible presets are compatible
with all the presets in the MK3 Top Boxes and are also compatible with previous generation tops and subs.
